Model Parameters Model CS-C3W-A0-3H4WFRL Camera Image Sensor 1/2.7”Progressive Scan CMOS Minimum Illumination 0.01 lux @(F1.6, AGC ON), 0 lux with IR Shutter Speed Self-adaptive shutter Lens 2.8 mm @F1.6, view angle: 100° horizontal, 121° diagonal 4 mm @F1.6, view angle: 82° horizontal, 97° diagonal Lens Mount M12 DNR 3D DNR WDR Digital WDR Compression Video Compression H.265 / H.264 Video Bit Rate Quad HD; Full HD; HD; Standard. Adaptive bit rate. General Working Temperature -30 °C to 60 °C (22 °F to 140 °F) Working Humidity 95% or less (non-condensing) Power Supply DC 12 V / 1 A Power Consumption Max. 6 W IP Grade IP67 Night Vision Distance (Black/White Night Vision Mode) Max. 30 m (98.43 ft.) Dimensions 72 mm × 72 mm × 150 mm (2.83” × 2.83” × 5.91”) Packaging Dimensions 252 mm × 110 mm × 92 mm (9.92” × 4.33” × 3.62”) Net Weight 395 g(0.87 lbs) Network User Defined Alarm Tones Supports Wi-Fi Pairing AP Pairing Protocol EZVIZ Cloud Proprietary Protocol Interface Protocol EZVIZ Cloud Proprietary Protocol General Function Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark Max. Bitrate 2M Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n Frequency Range 2.4 GHz ~ 2.4835 GHz Channel Bandwidth Supports 20 MHz Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Transmission Rate 11b: 11 Mbps, 11g: 54 Mbps, 11n: 144 Mbps Image Max. Resolution 2560 × 1440 Frame Rate Max: 30 fps; Self-adaptive during network transmission Interface Storage MicroSD card slot (Max. 256 GB) Wired Network RJ45 × 1(10 M / 100 M Adaptive Ethernet Port) In the box In the box C3W Pro (4MP) Color Night Vision Camera ; Power Adapter (1.5 m) ; Mounting Template ; Screw Kit ; Waterproof Kit ; Quick Start Guide Certifications: Certifications: UL / FCC / CE / WEEE / REACH / RoHS

Manufacturer Warranty: 2 Years Manufacturer Warranty
