Image sensor 1/2.8” Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens 4mm, view angle:106° (Horizontal), 122°(Diagonal)
4mm, view angle:86° (Horizontal), 102°(Diagonal)
Lens Mount M12
Day & Night IR-cut filter with auto switch
DNR 3D DNR
WDR WDR
BLC Supports
Night Vision Up to 98 ft. / 30 m
Max. Resolution 2304 × 1296
Frame Rate Max:25fps; Self-Adaptive during network transmission
Video Compression H.265/H.264
Video Bit Rate Ultra-HD; HD; Standard. Adaptive bit rate.
Audio Bit Rate Self-Adaptive
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol
Wired Network RJ45 × 1(10M/100M Adaptive Ethernet Port)
Smart Alarm Motion Detection, AI-Powered Human Shape Detection, Vehicle Shape Detection
Customized Alert Area  Supports
Two-way Talk Supports
General Function Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark
Local Storage Micro SD card slot (Max. 512G)
Cloud Storage EZVIZ Cloud Storage (Subscription required)
IP Grade IP67
Operating Conditions -30℃ ~ 50℃ Humidity 95% or less ( non-condensing)
Power Supply DC 12V/1A，Support PoE power supply
Power Consumption MAX. 8W
Dimensions  106mm*106mm*90mm
Packaging Dimensions 133mm*131mm*159mm
Weight Net Weight:240g
With Package: 400g
