• System parameters
• Operating systemEmbedded Linux operation system
• ROM16 MB
• RAM256 MB
• CPUEmbedded MCU Processor

• Display parameters
• Screen size/
• Operation method/
• Type/
• Resolution/

• Video parameters
• LensLow Illumination 2 MP HD IR Camera
• Resolution

  Main stream : 1920 × 1080

  Sub stream : 720 × 480

• FOVHorizontal: 180°, Vertical: 96°
• WDRSupported
• Supplement lightIR supplement
• Video compression standardH.264

• Audio parameters
• Audio compression standardG.711 U
• Audio inputBuilt-in omnidirectional microphone
• Audio outputBuilt-in loudspeaker (More than 85 dB within 20 cm)
• Audio compression bitrate64 Kbps
• Audio qualityNoise suppression and echo cancellation
• Volume adjustmentAdjustable

• Capacity
• User capacity/
• Face capacity/
• Card capacity/
• Linked network camera capacity100
• Holiday group16

• Network parameters
• Communication protocolTCP/IP, RTSP
• Wired networkSupport
• Wi-Fi standard/
• Bluetooth version/
• 3G/4G standard/

• Device interfaces
• Alarm input4
• Network interface1 10/100 Mbps self-adaptive Ethernet
• TAMPER1
• Exit button2
• RS-4851
• USB/
• Wiegand/
• TF card/
• Alarm output2
• Lock control2
• Door contact input2
• Power interface1

• Performances
• Multi-factor authentication/

• General
• Button/
• InstallationFlush mounting, surface mounting
• Indicator/
• Weight

  Without package: 415 g

  With package: 625 g

• Protective levelIP65
• Working temperature-40° C to +55° C(-40° F to 131° F)
• Working humidity10% to 95%
• Dimensions98 mm × 99.8 mm × 43.9 mm (3.86" × 3.93" × 1.73")
• Battery/
• Power supply

  IEEE802.3af, standard PoE

  12 VDC, 1 A

• Application environmentOutdoor
• Power consumption≤10 W
• LanguageEnglish, French, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Portuguese, Slovak

Manufacturer Warranty: 2 Years Manufacturer Warranty
