Lens FOV Horizontal field of view: 100° to 33° (Wide-Tele),Vertical field of view: 53° to 18° (Wide-Tele),Diagonal field of view: 119° to 37.5° (Wide-Tele) Focal Length 2.8 mm to 12 mm, 4× optical zoom Zoom Speed Approx. 2 s (optical lens, wide-tele) Working Distance 10 mm to 1500 mm (wide-tele) Aperture Range F1.6 to F2.7 Smart Features Basic Event Detection Motion Detection, Video Tampering Detection, Exception Smart Detection Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection Smart Record ANR (Automatic Network Replenishment), Dual-VCA ROI Main stream, sub-stream, and third stream respectively support two fixed areas. Network Security Measures User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering Network Storage Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour API Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform, support Hik-Connect Simultaneous Live View Up to 20 channels User/Host Up to 32 users,3 levels: Administrator, Operator and User Client iVMS-4200, HikCentral, HiLookVision Web Browser IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 Image Image Enhancement 3D DNR, BLC, HLC, EIS, Regional Exposure, Regional Focus Sub-Stream 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) Max. Resolution 2560 × 1440 Main Stream 50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 24fps (2560 × 1440), 30fps (2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) Third Stream 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288), 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) Interface Audio Input 1-ch audio input (line in) Audio Output 1-ch audio output (line out) Network Interface 1 RJ45 10 M/100 M Ethernet, PoE Built-in Microphone 1 built-in microphone, picking up sounds in the radius up to 5 meters Camera Module Image Sensor 1/3" progressive scan CMOS Min. Illumination Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR White Balance Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp Gain Auto/Manual Shutter Time 50Hz: 1/1 s to 1/30,000 s,60Hz: 1/1 s to 1/30,000 s Day & Night IR Cut Filter Digital Zoom 16× Privacy Mask 24 programmable privacy masks Focus Mode Auto/Semi-automatic/Manual WDR 120 dB WDR General Material Aluminum alloy, PC, PC+ABS Dimensions ? 130.7 mm × 101.7 mm (? 5.15" × 4.00") Weight Approx. 0.53 kg (1.17 lb) Protection Level IP66 Standard, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection Power 12 VDC, 1.5 A (Max. 9.9 W, including max. 4.2 W for IR) PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 11.2 W, including max. 4.2 W for IR) Working Temperature -20°C to 60°C (-4°F to 140°F) Working Humidity ? 90% Supplement Light IR Distance 20 m Smart IR Support PTZ Movement Range (Pan) 0° to 330° Pan Speed Configurable, from 0.1°/s to 100°/s, Preset speed: 100°/s Movement Range (Tilt) From 0° to 90° Tilt Speed Configurable, from 0.1°/s to 100°/s, Preset Speed: 100°/s Proportional Zoom Support Presets 300 Power-off Memory Support Compression Standard H.264+ Support H.265+ Support H.264 Type Baseline Profile/Main Profile/High Profile Video Compression Main Stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG H.265 Type Main Profile Video Bitrate 32 Kbps to 16384 Kbps Audio Compression G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM Audio Bitrate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps(MP2L2) SVC Support

Manufacturer Warranty : 3 years Manufacturer Warranty
