PoE Power Supply PoE Standard Ports 1 to 4: IEEE 802.3af, IEEE 802.3at PoE Power Pin Ports 1 to 4: Ethernet cables 1/2/3/6 and 4/5/7/8 provide power supply simultaneously. PoE Port Ports 1 to 4 Max. Port Power Ports 1 to 4: 30 W PoE Power Budget 35 W Network Parameters Port Number 4 x 10/100Mbps PoE ports, and and 2 × 10/100Mbps RJ45 ports Port Type RJ45 port, full duplex, MDI/MDI-X adaptive Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x Forwarding Mode Store-and-forward switching High priority ports Ports 1 and 2 Ports for Long-Distance Transmission Ports 1 to 4 MAC Address Table 4 K Switching Capacity 1.6 Gbps Packet Forwarding Rate 0.8928 Mpps Internal Cache 768 Kbits Dialing Function Long Range Ports 1 to 4: up to 250m. General Shell Metal material, fan-free design Gross Weight 0.52 Net Weight 0.265 Dimension (L × H × D) 145 mm × 68.45 mm × 25.6 mm (5.71” × 2.69” × 1.01”) Operating Temperature -10°C to 40°C (14°F to 104°F) Storage Temperature -40°C to 85°C (-40°F to 185°F) Operating Humidity 5% to 95% (no condensation) Storage Humidity 5% to 95% (no condensation) Power Supply 48 VDC, 0.8 A Power Consumption in Idle < 5 W Power Souce 38 W Max. Power Consumption 38 W Approval EMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000- 3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016) Safety UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CELVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013) Chemistry CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Manufacturer Warranty : 2 years Manufacturer Warranty
