Camera Image Sensor 1/1.8" Progressive Scan CMOS Max. Resolution 2688 × 1520 Min. Illumination Color: 0.002 Lux @ (F1.4, AGC ON),0 Lux with IR Shutter Time 1 s to 1/30,000 s Day & Night IR cut filter Angle Adjustment Pan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360° Lens Lens Type Varifocal lens, motorized lens, 6 to 60 mm Focal Length & FOV 6 to 60 mm, horizontal FOV 59.5° to 7.3°, vertical FOV 35.9° to 4.2°, diagonal FOV 66.5° to 8.3° Lens Mount Integrated Iris Type DC iris Aperture F1.4 Min. Focus Distance W: 1 m (3.3 ft) T: 3 m (9.8 ft) Depth of Field 2.5 m to ? DORI DORI Wide: D: 93.8 m, O: 37.2 m, R: 18.8 m , I: 9.4 m Tele: D: 827.6 m , O: 328.4 m, R: 165.5 m, I: 82.8 m Illuminator Supplement Light Type IR Supplement Light Range Up to 120 m Smart Supplement Light Yes IR Wavelength 850 nm Video Main Stream Monitoring mode: 50 Hz: up to 50 fps (1920 × 1080, 1280 × 720) 60 Hz: up to 60 fps (1920 × 1080, 1280 × 720) *High frame rate is supported under monitoring mode only. Smart Event/Face Capture Mode: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) Sub-Stream 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) Third Stream 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under Monitoring mode. Fourth Stream 50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) *Fourth stream is supported under Monitoring mode. Video Bit Rate 32 Kbps to 8 Mbps Video Compression Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 Fourth stream: H.265/H.264/MJPEG *Third stream and fourth stream are supported under Monitoring Mode. H.264 Type Baseline Profile/Main Profile/High Profile H.265 Type Main Profile Bit Rate Control CBR/VBR Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 5 fixed regions for main stream and sub-stream Target Cropping Yes Audio Audio Type Mono sound Environment Noise Filtering Yes Audio Sampling Rate 8 kHz/16 kHz/32 kHz/48 kHz Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Network Simultaneous Live View Up to 6 channels API ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, ARP, SNMP, SRTP, WebSocket, WebSockets User/Host Up to 32 users. 3 user levels: administrator, operator and user Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2, host authentication (MAC address) Network Storage NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported. Client iVMS-4200, Hik-Connect, Hik-Central Web Browser Plug-in required live view: IE11, Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+, Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+ Image Wide Dynamic Range (WDR) 120 dB SNR ? 52 dB Image Enhancement BLC, HLC, 3D DNR, Defog Privacy Mask 8 programmable polygon privacy masks Day/Night Switch Day, Night, Auto, Schedule Image Parameters Switch Yes Image Settings Saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser Interface Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB Audio 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 K?, interface type: non-equilibrium, 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 ?, interface type: non-equilibrium Alarm 3 inputs, 3 outputs (max. 24 VDC, 1 A) Reset Key Yes Event Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception Smart Event Scene change detection, audio exception detection Linkage Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,audible warning,trigger alarm output Deep Learning Function Perimeter Protection Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle) Face Capture Yes General Power 12 VDC ± 15%, 1.21 A, max. 14.5 W, 24 VAC ± 20%, 1.01 A, max. 14.5 W, two-core terminal block, PoE: IEEE 802.3at, Class 4, max. 18 W Material Front cover: metal, body: metal, bracket: metal Dimension 144 mm × 140 mm × 349.2 mm (5.7" × 5.5" × 13.7") Package Dimension 405 mm × 190 mm × 180 mm (15.9" × 7.5" × 7.1") Weight Approx. 2280 g (4.1 lb.) With Package Weight Approx. 3390 g (6.3 lb.) Storage Conditions -40 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Startup and Operating Conditions -40 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Language 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian General Function Heartbeat, anti-banding, mirror, flash log, password reset via email, pixel counter Approval EMC CE-EMC: EN 55032:2015+A11:2020+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021 Safety CE-LVD: EN 62368-1: 2014/A11: 2017, CB: IEC 62368-1: 2014, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005 Environment CE-RoHS: 2011/65/EU Protection IP67: IEC 60529:1989+AMD1:1999+AMD2:2013, IK10: IEC 62262:2002+AMD1:2021
