Video and Audio
IP Video Input
4-ch
Incoming Bandwidth
40 Mbps
Outgoing Bandwidth
80Mbps
HDMI Output
HDMI:,4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,VGA: ,1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
VGA Input
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode
HDMI/VGA simultaneous output
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1kΩ)
Decoding
Decoding Format
H.265+,H.265,H.264+,H.264,MPEG4
Recording Resolution
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/ 720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous playback
4-ch
Decoding Capability
1-ch @ 8 MP / 4-ch @ 1080p
Network
Remote Connection
32
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface
1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
PoE
Interface
4-ch, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power
≤ 50 W
Standard
IEEE 802.3 af/at
Auxiliary Interface
SATA
1 SATA interface
Capacity
Up to 8 TB capacity for each disk
USB Interface
2 × USB 2.0
General
Power Supply
48 VDC, 1.35 A
Consumption
≤ 10 W (without HDD and PoE off)
Working Temperature
-10 to +55° C (14 to 131° F)
Working Humidity
10% to 90%
Chassis
1U
Dimension (W × D × H)
265 × 225 × 48 mm (10.2" × 8.9" × 1.9")
Weight
≤ 1 kg (without HDD, 2.2 lb.)

Manufacturer Warranty : 3 years Manufacturer Warranty
