Video and Audio
IP Video Input
16-ch
HDMI Output
1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output
1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Incoming Bandwidth
160 Mbps
Outgoing Bandwidth
80 Mbps
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 k Ω)
Decoding
Decoding Format
H.265+,H.265,H.264+,H.264
Decoding Capability
4-ch@1080p
Synchronous playback
16-ch
Recording Resolution
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Network
Network Protocol
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Interface
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interface
16-ch
Power
≤ 150W
Standard
IEEE 802.3 af/at
RAID
RAID Type
No
Auxiliary Interface
SATA
2 SATA interfaces
Capacity
Up to 8TB capacity for each disk
USB Interface
2 × USB 2.0
General
Power Supply
100-240V～, 50/60Hz, 3.2A MAX
Consumption
≤ 15W
Working Temperature
-10 to +55º C (+14 to +131º F)
Working Humidity
10 to 90 %
Chassis
1U chassis
Dimension (W × D × H)
385 × 315 × 52 mm (15.2"× 12.4" × 2.0")
Weight
≤ 2.6 kg (5.7 lb)
