Camera Image Sensor 3K CMOS Max. Resolution 2960 (H) × 1665 (V) Min. Illumination 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR Shutter Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s Day & Night ICR Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 75°, Rotate: 0 to 360° Signal System PAL/NTSC Lens Lens Type 2.8 mm and 3.6 mm fixed focal lens Focal Length & FOV 2.8 mm, horizontal FOV: 104.9°, vertical FOV: 67.3°, diagonal FOV: 129.8° 3.6 mm, horizontal FOV: 81.3°, vertical FOV: 50.7°, diagonal FOV: 102.4° Lens Mount M12 Illuminator Supplement Light Type White Light;IR Supplement Light Range IR : up to 40 m White Light : up to 20 m Image Image Settings Brightness, Sharpness, Smart IR Frame Rate TVI: 3K @20 fps, 4 MP @25 fps/30 fps, 1080p @25 fps/30 fps AHD: 5 MP @20 fps, 4 MP @25 fps/30 fps CVI: 4 MP @25 fps/30 fps CVBS: PAL/NTSC Day/Night Mode Auto/Color/BW (Black and White) Wide Dynamic Range (WDR) Digital WDR Image Enhancement DWDR/BLC/HLC/Global White Balance Auto/Manual AGC Yes Interface Video Output Switchable TVI/AHD/CVI/CVBS Built-in Microphone Yes General Material Body: metal Enclosure: metal Dimension Ø127.9 mm × 97.8 mm (Ø5.04" × 3.85") Weight Approx. 476 g (0.75 lb.) Operating Condition -40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensation) Communication HIKVISION-C Language English Power Supply 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. Consumption Max. 3.3 W Approval Protection IP66

Manufacturer Warranty : 3 years Manufacturer Warranty
