Camera Shutter Speed 1/3 s to 1/100,000 s P/N PAL: 25fps NTSC: 30fps Day & Night IR Cut Filter Angle Adjustment Pan: -20° to 0°, Tilt: -15° to 25° White Balance Support 4 white balance configurations: fluorescent lamp, incandescent lamp, warm lamp and natural light; Support manual/automatic white balance adjustment. Lens Focal Length 2.8mm/4mm/6mm Focal Length & FOV 2.8mm: horizontal FOV 105°, vertical FOV 56°, diagonal FOV 126° 4mm: horizontal FOV 87°, vertical FOV 44°, diagonal FOV 104° 6mm: horizontal FOV 53°, vertical FOV 28°, diagonal FOV 62° Lens Mount M12 Focus Manual focus Max. Aperture 2.8/4/6mm : F1.6 Illuminator Supplement Light Type Infrared fill light lamp Smart Supplement Light Support IR Wavelength 850 nm IR Range Up to 30 m Video Max. Resolution 1920 x 1080 Main Stream 50Hz: 25 fps (1920 x 1080, 1280 x 960, 1280 x 720) 60Hz: 30 fps (1920 x 1080, 1280 x 960, 1280 x 720) Sub-Stream 50Hz: 25 fps (704 x 576, 640 x 480, 352 x 288, 320 x 240) 60Hz: 30 fps (704 x 576, 640 x 480, 320 x 240) Third Stream 50Hz: 25 fps (1920 x 1080, 1280 x 960, 1280 x 720) 60Hz: 30 fps (1920 x 1080, 1280 x 960, 1280 x 720) Video Compression Main stream: H.264, H.265, H.264+, H.265+ Sub-stream: H.264, H.265, MJPEG, H.264+, H.265+ Third stream: H.264, H.265 ,H.264+, H.265+ Video Bit Rate Main Stream: 256 Kbps to 12288Kbps Sub-Stream: 256 Kbps to 4096Kbps Third Stream: 256 Kbps to 12288Kbps H.264 Type BaseLine Profile/Main Profile/High Profile H.265 Type Main Profile Bit Rate Control Constant Bit Rate, Variable Bit Rate Stream Type Main stream, sub stream, third stream Scalable Video Coding (SVC) H.264 and H.265 encoding Region Of Interest (ROI) Support 2 fixed region for (main/sub) stream Network Protocols TCP/IP,HTTP,HTTPS,DHCP,DNS,DDNS ,RTSP,SNMP,QOS,FTP,RTCP,NTP,UPNP,SMTP,IGMP,ICMP,IPV6,UDP,SSL/TLS Simultaneous Live View Up to 8 channels API ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK User Management Up to 16 users, 3 levels: Administrator, Operator and User Web Browser IE8+, Chrome45+, Edge41+, Firefox45+ Image Wide Dynamic Range (WDR) 120 dB Image Settings Support rotation mode. Brightness, contrast, saturation and sharpness can be adjusted by browser and client software. Day/Night Switch Day/Night/Auto/Schedule SNR > 50 dB Image Enhancement BLC, HLC, 2DNR ,3DNR Privacy Mask Enables configuration, and supports drawing of up to 4 areas Picture Overlay Support image overlay, uploading images, enabling, coordinates, etc. Target Cropping Support (only the third stream) Backlight Compensation(BLC) Support up, down, left, right, center and custom backlight compensation adjustment Interface Video Output Not supported Ethernet Interface -ID: 1 RJ45 10M/100M self-adaptive Ethernet port -IM/ND, IDM: 1 four-core M12 aviation plug Reset Key Support Interface Type Interpolate TF Card Storage Built-in Micro TF Slot, up to 256 GB(not for baseline. Note the Micro-TF card capacity when ordering) Event Linkage Method Upload to FTP, notify monitoring center, send email, trigger recording Basic Event Motion detection, video tampering alarm Smart Event Line crossing detection, Intrusion detection, Region entrance detection, Region exiting detection, Unattended baggage detection, Object removal detection, Object detection: detects faces and upload images Scene change detection, defocus detection, Loitering Detection, People Gathering Detection, Fast Moving Detection, Parking Detection, General Product Dimension Camera: ? 78.8 mm × 81.6mm x 63.8 mm (3.1? × 3.2? x 2.5?) Power PoE: 0.30 A to 0.20 A, max: 7.5 W DC: 0.83 A to 0.21 A, max: 7.5 W Package Dimension 174 mm × 111 mm × 101mm (6.85? × 4.37? × 3.98?) Product Weight Approx. 330 g (0.7 lb.) Startup and Operating Conditions -30 °C to 75 °C (-22 °F to 167°F), humidity less than 95% or less (non-condensing) Language English, French, German, Russian, Italian, Korean, Portuguese, Spanish, Turkish, Polish, Czech General Function Anti-flicker, heartbeat, mirror Software Reset Support Power Supply -ID: 9-36V& PoE (802.3af, 36 V to 57 V) -IDM: 9-36V& PoE (802.3af, 36 V to 57 V) -IM/ND: PoE (802.3af, 36 V to 57 V) Power Interface -ID: Ø 5.5 mm coaxial power plug, DC power supply, or PoE power supply -IM/ND: four-core M12 aviation plug, PoE power supply Cable Length 50 cm Approval Class Class B EMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); Safety UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); LOA: SANS IEC60950-1 BIS: IS 13252(Part 1)2010+A1:2013+A2:2015 Environment CE-RoHS (2011/65/EU); WEEE: 2012/19/EU Reach SVHC: Regulation (EC) No 1907/2006 Electrical Safety Protection IP68 (IEC 60529-2013) Automotive and Railway EN50155-2017(EN 50155:2017, EN 50121-3-2:2016, IEC 60068-2-1:2007, IEC 60068-2- 2:2007, IEC 60068-2-30:2005, IEC 61373:2010); EN45545 (EN 45545-2:2013+A1:2015); E-MARK (ECE R10)
