NFO

• Product name

  UltraGear

  Year

  Y23

DISPLAY

• Size (Inch)

  26.5

  Size (cm)

  67.32 cm

• Resolution

  2560 x 1440

  Panel Type

  OLED

• Local Dimming Zone

  N/A

  Aspect Ratio

  16:9

• Pixel Pitch

  110.8 PPI

  Brightness (Min.)

  160 cd/m²

• Brightness (Typ.)

  200 cd/m²

  Peak Brightness (Min.)

  800cd/m² (@HDR 3% APL)

• Peak Brightness (Typ.)

  1000cd/m² (@HDR 3% APL)

  Colour Gamut (Min.)

  DCI-P3 90% (CIE1976)

• Colour Gamut (Typ.)

  DCI-P3 98.5% (CIE1976)

  Colour Depth (Number of Colours)

  1.07B

• Colour Bit

  10bit

  Contrast Ratio (Min.)

  -

• Contrast Ratio (Typ.)

  1500000:1

  Response Time

  0.03ms (GtG)

• Refresh Rate (Max.) [Hz]

  240

  Viewing Angle (CR≥10)

  178º(R/L), 178º(U/D)

• Surface Treatment

  Anti-Glare, Low-Reflection of the front polarizer

  Curvature

  NO

FEATURES

• HDR 10

  YES


  Dolby Vision™

  NO

• VESA DisplayHDR™

  NO

  HDR Effect

  YES


• Mini-LED Technology

  NO

  Nano IPS™ Technology

  NO

• Advanced True Wide Pol.

  NO

  Colour Calibrated in Factory

  Yes

• HW Calibration

  HW Calibration Ready

  Auto Brightness

  NO

• Flicker safe

  NO

  Picture Mode

  (Non HDR Contents) → Gamer 1, Gamer 2, FPS, RTS, Vivid, Reader, HDR Effect, sRGB, Colour Weakness, Calibration 1, Calibration 2 (HDR Contents) → Gamer 1, Gamer2, FPS, RTS, Vivid

• Reader Mode

  YES

  Colour Weakness

  Yes

• Super Resolution+

  NO

  Motion Blur Reduction Tech.

  NO

• MBR(Supported Frequency)

  N/A

  NVIDIA G-Sync™

  G-SYNC Compatible

• AMD FreeSync™

  FreeSync Premium

  VRR

  YES

• Black Stabiliser

  Black Stabiliser

  Dynamic Action Sync

  YES

• Crosshair

  Yes

  FPS Counter

  YES

• OverClocking

  NO

  User Defined Key

  YES

• Auto Input Switch

  YES

  RGB LED Lighting

  Hexagon Lighting

• PBP

  NO

  PIP

  NO

• Smart Energy Saving

  YES

  OSD Language

  17 countries (English, Germanic, French, Spanish, Italian, Swedish, Finnish, Portuguese, Portuguese(brazil), Polish, Russian, Turkish, Ukrainian, Chinese, Traditional Chinese, Japanese, Korean)

• Camera

  NO

  Mic

  NO

• Others (Feature)

  Hexagon Lighting, VESA DSC Tech. DTS HP:X (4-pole H/P Out)

SW APPLICATION

• LG Calibration Studio (True Colour Pro)

  Yes

  Dual Controller

  NO

• OnScreen Control (LG Screen Manager)

  YES

  LG UltraGear™ Control Center

  NO

• LG UltraGear™ Studio

  NO

CONNECTIVITY

• D-Sub

  NO

  D-Sub (V Frequency)

  N/A

• D-Sub (Max. Resolution at Hz)

  N/A

  DVI-D

  NO

• DVI (V Frequency)

  N/A

  DVI (Max Resolution at Hz)

  N/A

• HDMI

  YES(2ea)


  HDMI Version

  2.1

• HDMI (HDCP Version)

  2.3

  HDMI (w/o VRR)

  48 ~ 240Hz

• HDMI (w/ VRR)

  48 ~ 240Hz

  DisplayPort

  YES(1ea)

• DP Version

  1.4

  DP (HDCP Version)

  2.3

• DP (w/o Adaptive-Sync)

  48 ~ 240Hz

  DP (w/ Adaptive-Sync)

  48 ~ 240Hz

• Thunderbolt

  No

  Thunderbolt Version

  N/A

• Thunderbolt (HDCP Version)

  N/A

  Thunderbolt (V Frequency)

  N/A

• Thunderbolt (Max. Resolution at Hz)

  N/A

  Thunderbolt (Data Transsmission)

  No

• Thunderbolt (Power Delivery)

  N/A

  USB-C

  NO

• USB-C (DP Version)

  N/A

  USB-C (HDCP Version)

  N/A

• USB-C (V Frequency)

  N/A

  USB-C (Max. Resolution at Hz)

  N/A

• USB-C (Data Transsmission)

  NO

  USB-C (Power Delivery)

  N/A

• Daisy Chain

  NO

  USB Upstream Port

  YES (1ea/ver3.0)

• USB Downstream Port

  YES(2ea/ver3.0)

  Built-in KVM

  NO

• LAN (RJ-45)

  NO

  SPDIF out (Optical Digital Audio Out)

  YES

• Audio In

  No

  Mic In

  No

• Headphone Out

  4-pole (Sound+Mic)

  Line out

  No

• [Location]

  Rear

SOUND

• Speaker

  NO

  Bluetooth Conectivity

  NO

• DTS HP:X

  YES

  Maxx Audio

  NO

• Rich Bass

  NO

POWER

• Type

  External Power(Adapter)

  AC Input

  100~240V (50/60Hz)

• DC Output

  19V, 5.79A

  Power Consumption (Typ.)

  74W

• Power Consumption (Max.)

  94W

  Power Consumption (Energy Star)

  N/A

• Power Consumption (Sleep Mode)

  Less than 0.5W

  Power Consumption (DC Off)

  N/A

MECHANICAL

• Borderless Design

  4-Side Virtually Borderless Design

  Colour (Front Cabinet)

  N/A

• Colour (Middle Cabinet)

  Purple Gray

  Colour (Back Cover)

  Purple Gray

• Colour (Stand Body)

  Purple Gray

  Colour (Stand Base)

  Purple Gray

• Display Position Adjustments

  Tilt/Height/Swivel/Pivot

  Tilt

  -5~15º

• Swivel

  -10~10º

  Height Range

  110mm

• Down Height

  123.7mm

  Pivot

  Counterclockwise

• Extend/Retract

  N/A

  Wall Mountable

  100 x 100 mm

• Base Detachable

  YES

  OneClick Stand

  YES

DIMENSIONS/WEIGHT

• Dimension with Stand (W x H x D)

  604.4 x 574.4 x 258 (UP) / 604.4 x 464.4 x 258 (DOWN)

  Dimension without Stand (W x H x D)

  604.4 x 350.6 x 45.3

• Dimension in Shiping (W x H x D)

  808 x 181 x 532

  Weight with Stand

  7.35kg

• Weight without Stand

  5.05kg

  Weight in Shipping

  11kg

• Pallet Stuffing (20ft/40ft/40ft HC)

  264/616/728

STANDARD

• TCO

  NO

  EPA

  NO

• TUV-TYPE

  YES

  TUV-GS

  NO

• TUV-Ergo

  NO

  CB

  YES

• UL (cUL)

  YES

  FCC-B

  YES

• EPEAT (USA)

  NO

  EPEAT (Germany)

  NO

• ErP

  YES

  CE

  YES

• BIS (for India)

  YES

  VCCI (for Japan)

  YES

• BSMI (for Taiwan)

  NO

  KC (for Rep. of Korea)

  YES

• CCC (for China)

  YES

  Thunderbolt

  NO

• USB-C (USB-IF)

  NO

  USB-C (VESA)

  NO

• VESA wall mount standard

  NO

  Others (Standard)

  CEC,G-SYNC Compatible, FreeSync Premium, ISTA

ACCESSORY

• Adapter

  YES

  Adapter (Colour)

  Black

• Power Cord

  YES

  Power Cord (Colour/Length)

  Black / 1.5m

• D-Sub

  NO

  D-Sub (Colour/Length)

  NO

• DVI-D

  NO

  DVI-D (Colour/Length)

  NO

• HDMI

  YES (ver 2.1)

  HDMI (Colour/Length)

  Black/1.8m

• Display Port

  Yes

  Display Port (Colour/Length)

  Black/1.8m

• Thunderbolt

  NO

  Thunderbolt (Colour/Length)

  NO

• USB Type C

  NO

  USB Type C (Colour/Length)

  No

• USB A to B

  YES

  USB A to B (Colour/Length)

  Black / 1.8m

• Remote Controller

  YES

  Remote Controller (Colour)

  Black

• Calibration Report (Paper)

  YES

  Others (Accessory)

  Stand Cable holder, Screw Driver

Manufacturer Warranty: 2 years Manufacturer Warranty
