Simple & flexible storage expansion for Enterprise ZFS NAS

The EJ1600 v2 expansion enclosure is designed for expanding the storage space on a QNAP Enterprise ZFS NAS by connecting multiple expansion enclosures via high-speed mini SAS cables. Featuring a 12 Gbps SAS interface on the chassis, the EJ1600 v2 ensures fast data passthrough from 12 Gbps SAS-enabled Enterprise ZFS NAS. This is especially useful for virtualization applications and large data applications that require high-performance interconnection, such as video surveillance, archiving large data, and TV broadcast storage, to provide businesses with optimized efficiency and maximized ROI. The EJ1600 v2 connects to the Enterprise ZFS NAS via the dual path mini-SAS design to sustain continuous operations even if an external JBOD cable is disconnected.

  • Dual-channel (Dual Path) to tolerate single node failure for uninterrupted operations
  • Missing Mode protection
  • High density, high efficiency and high scalability
  • Flexible management with the QES Storage Manager
  • Ideal backup storage for the dual-controller Enterprise ZFS NAS


Supported Enterprise ZFS NAS models and the maximum number of applicable expansion enclosures.

QNAP NAS ES1640dc v2
RAM of NAS 32GB / each controller
Maximum number of EJ1600 v2 7
Maximum number of hard drives 128
Maximum raw capacity* 1280 TB
Maximum number of RAID groups per storage pool 128
Maximum storage pool size 1 PB
Maximum number of storage pools per system 128
Maximum flexible volume size 1 PB
Maximum iSCSI LUN size 1 PB

Dual path design to ensure continuous operations

The EJ1600 v2 and Enterprise ZFS NAS all provide dual-channel (Dual Path) to tolerate single node failure. Even if an external JBOD cable is disconnected due to external damage to the mini-SAS cable, it can still run normally. This is essential for intermachine data protection and capacity scalability for uninterrupted mission-critical enterprise tasks. Simply connect a EJ1600 v2 to an Enterprise ZFS NAS and power it on, the NAS will detect hard drives in the EJ1600 v2 as newly-installed local drives. You can seamlessly expand and manage the NAS capacity by using the powerful QES Storage Manager.

As shown in the above figure, the cabling method used to connect expansion units creates a redundant cross loop configuration. This provides the expansion units with redundant paths to the base Enterprise ZFS NAS. Moreover, system failover protection includes protection of JBOD connection failure to provide an extra layer of protection. With these two protection methods, when one or multiple paths to the EJ1600 v2 disconnect, other expansion units are still able to communicate with the base Enterprise ZFS NAS.

Missing Mode protection

When the disconnection of a RAID expansion enclosure is detected, the Enterprise ZFS NAS blocks IO access to protect data. The system can recover from missing mode to its normal state with the data staying intact.

High density, high efficiency and highly scalable

The EJ1600 v2 supports 16 hard drives and 160TB raw capacity in 3U rack space. The EJ1600 v2 has two SAS wide ports (IN and OUT ports) for each controller (with 4 SAS wide ports in total with dual controllers) for host connectivity and daisy-chaining respectively. Each SAS wide port combines four SAS channels, with each supporting 12 Gbps full duplex speed. The solution delivers unprecedented performance of up to 48 Gbps per host connection.

Powerful QES Storage Manager

The QES Storage Manager neatly presents tools and options for managing system storage with an intuitive graphical user interface, which simplifies the process of NAS capacity expansion and EJ1600 v2 management. IT administrators can easily monitor the health of the EJ1600 v2 and the disks within it. When cascading multiple expansion enclosures in a rack, the Locate Disk and Locate Enclosure functions assist IT administrators in quick maintenance.

An excellent backup solution for Enterprise ZFS NAS

In addition to expanding an existing volume, IT administrators can use the EJ1600 v2 as a cost-effective external storage to perform speedy and secure backup tasks for an Enterprise ZFS NAS. The QNAP RTRR (Real-Time Remote Replication) or rsync service lets IT administrators back up NAS data to the EJ1600 v2 on a real time or scheduled basis.

Flexible drive type and capacity

The EJ1600 v2 offers high flexibility in hard drive selection. IT administrators can choose enterprise-level SAS HDDs with high performance and high reliability for mission-critical applications, or high-speed SSDs for I/O-intensive operations.



  • Plug and use, flexibly scale up Enterprise ZFS NAS storage capacity
  • Excellent backup solution for Enterprise ZFS NAS
  • Supports SAS 6 Gbps or SAS 12 Gbps hard drives and SSDs

Hardware Spec.

Host Interface Three SAS 12Gb/s 4x wide port (SFF-8644)
Hard Drive 16 x 3.5"/2.5" SAS 12Gbps/6Gbps hard drive, or 2.5" SAS SSD; lockable tray
LED Indicators System Power LED (Blue): on/off
System Status (Green/ Red): in operation, system errors, low power, disk lost, disk failure, system performing take-over, power supply unit unplugged
LCD Status Display (Two-digit number): Status of JBOD connection
Form Factor 3U rackmount
Dimensions 618 (D) x 446.2 (W) x 132 (H) (excluding front grips)
Weight Net weight (NAS only): 24.11 kg/ 53.15 lb
Gross weight (with packing and accessories): 33.76 kg/ 74.43 lb
Temperature 0- 40˚C
Humidity 5~95% RH non-condensing, wet bulb: 27˚C
Power Consumption (In Operation) 344.19 W
Sound Level* Sound pressure (LpAm): 53.5 dB(A)
Power Supply Redundant/ Hot Swap ATX Power Supply, 450W, 90-240Vac~, 50-60Hz
Fan Hot-swappable fan module (60*60*38mm; 16000RPM/12v/2.8A x 3)
Electro-Magnetic Compatibility (EMC) • FCC Class A (USA only)
• CE Mark ( EN55022 Class A, EN55024)
SAFETY Standard • EN60950
• CB


1. Hard Drive Tray
2. Hard Drive LED Indicators
3. Power On Button
4. LED Indicators
System Power LED (Blue): on/off
System Status (Green/ Red): in operation, system errors, low power, disk lost, disk failure, system performing take-over, power supply unit unplugged
LCD Status Display (Two-digit number): Status of JBOD connection


1. Power Supply LED (Green/ Orange) 6. COM Port x 2
2. Power Button 7. Controller Status Light (Green/ Orange)
3. Mini-SAS Port (SFF-8644) (Reserved) 8. Fan Status Light (Green/ Orange)
4. Mini-SAS Port (SFF-8644) Input 9. Battery Status Light (Green/ Orange)
5. Mini-SAS Port (SFF-8644) Output 10. High Availability LED (Green/ Orange)


* Testing Environment:
Refer to ISO 7779 ; Maximum HDD loaded ; Bystander Position ; Average data from 1 meter in front of operating NAS


Software Spec.

Expansion Enclosure Management

The functions listed below are managed via the QNAP QES operating system.

  1. Support for hard disk’s S.M.A.R.T. capacity
  2. RAID expansion enclosure LED identifier
  3. Location indication of RAID expansion enclosure
  4. Location indication of hard disks on RAID expansion enclosure
  5. Smart fan control
  6. In-band firmware update

The disks, RAID Groups, storage pools, and volumes in the RAID expansion enclosures are configured via the QES operating system.

  1. Upto 1PB Single Volume
  2. Support for multiple RAID groups in a storage pool to ensure data safety
  3. Online storage pool expansion
  4. Online volume expansion
  5. Block-based iSCSI LUN
  6. Support for thin-provisioned volume with space reclamation
  7. Support for thin-provisioned iSCSI LUN with space reclamation
High Availability Based On Dual Active Controller / Dual Loop

Superior High Availability

  1. Dual controller, dual-loop architecture to tolerate the failure of a single node
  2. Dual back-end IO paths (dual controller configuration)
  3. Topology:
    • Single controller, single
    • Single controller, multiple path, loop
    • Dual-controller, single path
    • Dual-controller, multiple path, loop


  1. Support disks up to 16
  2. Support cascade JBOD configuration to connect more JBODs, up to 6 sets

Superior FRU Design

  1. Hot swappable PSU module, disks and controller module, for easier maintenance and deployment
  2. Dual Slim type PSU module

Intelligent Storage Manager

The QES Storage Manager neatly presents tools and options for managing system storage with an intuitive graphical interface. From reviewing the system storage allocation in the Dashboard, to managing volumes, Storage Pools, disks and iSCSI storage, the Storage Manager provides a centralized place to ease the work of storage management.



SKU EJ1600-v2
Barcode # 885022012459
Brand QNAP
Shipping Weight 32.8700kg
Shipping Cubic 0.032870000m3
Manufacturer Warranty
2 Years Limited Warranty
