Ubiquiti Networks AF-24HD 24GHz Full-Duplex Point-to-Point Gigabit Radio
Model# AF-24HD
-
SKU: AF-24-HD
-
- Pick Up Available
- Australian Warranty
- Checkout Securely
24 GHz Full Duplex Point-to-Point 2 Gbps Radio
Featuring our INVICTUS™ custom silicon for 2+ million packets-per-second processing, the airFiber®24HD is ideal for outdoor, PtP bridging and backhaul applications requiring maximum performance.
Revolutionary Performance
Featuring the world’s best unlicensed-band spectral efficiency at 15.9 bps/Hz, the airFiber®24 HD supports the dense modulation rates, up to 256QAM, that are required for high data rates, up to 2 Gbps.
Proven Links: 20+ km
The airFiber®24 HD features the most powerful automatic compensation for path loss degradation due to rain fade, so it provides the best range – up to 20+ km – among 24 GHz products and allows for constellation threshold extension.
Low-Latency Carrier Backhaul
The airFiber®24 HD supports FDD (Frequency Division Duplexing) in full-duplex mode for 0.2 millisecond latency, resulting in increased efficiency for carrier-class network backhauls.
24 GHz Unlicensed Band
The airFiber®24 HD operates in worldwide, license-free, 24 GHz frequencies. Users can deploy airFiber®24HD almost anywhere they choose (subject to local country regulations).
Ubiquiti Networks AF-24HD 24GHz Full-Duplex Point-to-Point Gigabit Radio - 2Gbps Real Data Throughput - 20+ Km Extreme Range - 1x 10/100/1000 Ethernet Port, 1x 10/100 Ethernet Port, 1x RJ-12 Alignment Tone Port - 1 Year Warranty
(AF-24-HD)
| Antenna | Yes |
| Dimension | 649 x 426 x 303 mm |
| Gain | 23 dBi |
| Interface | WiFi |
| Mounting | Pole Mount Kit (Included) |
| Weight | 10.5 kg (Mount Included) |
| SKU | AF-24-HD |
| Barcode # | 810354021930 |
| Brand | Ubiquiti |
| Shipping Weight | 15.6800kg |
| Shipping Width | 0.730m |
| Shipping Height | 0.410m |
| Shipping Length | 0.520m |
| Shipping Cubic | 0.155636000m3 |
- Manufacturer Warranty
- 1 Year Manufacturer Warranty
- Manufacturer Contact Info
- https://www.ubnt.com/
