Epson LX-350 9-Pin Dot Matrix Printer 390cps USB Serial Parallel (C11CC24041)
Model # C11CC24041
-
SKU: C11CC24041
Don't pay: $449.00
$444.00
SAVE $5.00 (1%)
- Pick Up Available
- Australian Warranty
- Checkout Securely
Compact 9-pin dot matrix printing at up to 390cps
The Epson LX-350 is a compact 9-pin impact dot matrix printer for continuous paper and multi-part stationery, with USB, serial and parallel interfaces.
Print head9-pin
Maximum listed speed390cps
Ribbon yieldApprox. 4 million characters
MTBFApprox. 10,000 hours
Continuous and multi-part paper handling
The LX-350 supports cut sheets, continuous paper, envelopes and roll paper. Multi-part handling is listed for an original plus four copies.
Straightforward integration
Bi-directional parallel, serial and USB 2.0 full-speed interfaces are standard. A compact design and cable-management system support tidy desk placement.
Reliability and operating efficiency
The supplied page lists an approximate 10,000-hour mean time between failure, a four-million-character ribbon life, 1.1W standby consumption and 27W when powered on.
Technical specifications
| Product details | |
|---|---|
| Brand | Epson |
| Model | LX-350 |
| SKU | C11CC24041 |
| Printer type | Impact dot matrix |
| Print head | 9 pins |
| Print direction | Bi-directional with logic seeking |
| Performance and paper handling | |
| Maximum listed print speed | 390cps at 15cpi, High Speed Draft |
| Paper paths | Manual insertion: rear in, top out; tractor: rear in, top out |
| Copies | Original plus 4 copies |
| Input data buffer | 128KB |
| Connectivity and reliability | |
| Parallel interface | Bi-directional IEEE-1284 nibble mode supported |
| Serial interface | Yes |
| USB | USB 2.0 full speed |
| Ribbon life | Approx. 4 million characters |
| MTBF | Approx. 10,000 power-on hours at 25% duty cycle |
| Acoustic noise | Approx. 53dB(A) |
Frequently asked questions
How fast is the Epson LX-350?
The highest supplied print-speed value is 390 characters per second at 15cpi in High Speed Draft mode.
Which interfaces are standard?
Parallel, serial and USB interfaces are listed as standard.
Can it handle multi-part stationery?
Yes. The supplied specifications list an original plus four copies.
(C11CC24041)
| Printer Type | Impact Dot Matrix | ||
|---|---|---|---|
| Product Name | LX-350 | ||
| Product Code | C11CC24041 | ||
| Printing Method | Impact dot matrix | ||
| Number of Pin in Head | 9 pins | ||
| Print Direction | Bi-directional with logic seeking |
| Print Speed | |||
|---|---|---|---|
| High Speed Draft | 10 CPI 347 cps 12 CPI 357 cps 15 CPI 390 cps |
||
| High Speed Draft Condensed | 17 CPI 383 cps 20 CPI 298 cps |
||
| Draft | 10 CPI 260 cps 12 CPI 312 cps 15 CPI 223 cps |
||
| Draft Condensed | 17 CPI 222 cps 20 CPI 260 cps |
||
| Draft Emphasized | 10 CPI 130 cps | ||
| NLQ | 10 CPI 65 cps 12 CPI 78 cps 15 CPI 55 cps 17 CPI 47 cps 20 CPI 56 cps |
| Print Characteristics | ||||||
|---|---|---|---|---|---|---|
| Character Sets | 15 International character sets, 13 character code tables (Standard), Italic, PC437, PC850, PC860, PC861, PC863, PC865, Abicomp, BRASCII, Roman 8, ISO Latin 1, PC858, ISO 8859-15 NLSP version (43 character tables) Italic table, PC437 (US Standard Europe), PC850 (Multilingual), PC860 (Portuguese), PC861 (Icelandic), PC863 (Canadian-French), PC865 (Nordic), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC 858, ISO 8859-15, PC437 Greek, PC852 (East Europe), PC853 (Turkish), PC855 (Cyrillic), PC857 (Turkish), PC866 (Russian), PC869 (Greek), MAZOWＩA (Poland), Code MJK (CSFR), ISO 8859-7 (Latin, Greek), ISO Latin IT (Turkish), Bulgaria (Bulgarian), Estonia (Estonia), PC774 (LST 1283:1993), ISO 8859-2, PC 866UKR (Ukraina), PC771 (Lithuania), PC437 Slovenia, PC MC, PC1250, PC1251, PCAPTEC (Arabic), PC708 (Arabic), PC720 (Arabic), PCAR 864 (Arabic), PC866LAT(Latvian), Hebrew8*1, Hebrew7*1, PC862(Hebrew)*1, KZ1048(Kazakhstan) |
|||||
| Bitmap Fonts |
|
|||||
| Bar Code Font | EAN-13, EAN-8, Interleaved 2 of 5, UPC-A UPC-E, Code 39, Code 128, PostNet |
| Printable Columns | |||
|---|---|---|---|
| Pitch (CPI) | Character per line | ||
| 10 CPI | 80 | ||
| 12 CPI | 96 | ||
| 15 CPI | 120 | ||
| 17 CPI | 137 | ||
| 20 CPI | 160 |
| Paper Handling | |||
|---|---|---|---|
| Paper Path | Manual Insertion:Rear in, Top out | ||
| Tractor: Rear in, Top out |
| Paper Size | |||
|---|---|---|---|
| Cut Sheet | Manual Insertion | Width: 100 ~ 257 mm (3.9 ~ 10.1") Length: 100 ~ 364 mm (3.9 ~ 14.3") Thickness: 0.065 ~ 0.14 mm (0.0025 ~ 0.0055") |
|
| Cut Sheet Multi Part | Width: 100 ~ 257 mm (3.9 ~ 10.1") Length: 100 ~ 364 mm (3.9 ~ 14.3") Thickness: 0.12 ~ 0.39 mm (0.0047 ~ 0.015") (Total) |
||
| Envelope | No.6 | Width: 165 mm (6.5") Length: 92 mm (3.6") Thickness: 0.16 ~ 0.52 mm (0.0063 ~ 0.0205") (Total) |
|
| No.10 | Width: 241 mm (9.5") Length: 105 mm (4.1") Thickness: 0.16 ~ 0.52 mm (0.0063 ~ 0.0205") (Total) |
||
| Continuous Paper (Single sheet and Multi Part) |
Width: 101.6 ~ 254 mm (4.0 ~ 10.0") Length: 101.6 ~ 558.8 mm (4.0 ~ 22.0") Thickness: 0.065 ~ 0.39 mm (0.0025 ~ 0.015") (Total) |
||
| Roll Paper | Width: 216 mm (8.5 ") Thickness: 0.07 ~ 0.09 mm (0.0028 ~ 0.0035") |
||
| Paper Feeding | Standard | Friction, Push Tractor |
|
| Optional | Roll Paper Holder | ||
| Copies | Original +4 Copies | ||
| Line Spacing | 4.23 mm (1/6 inch) or programmable in increments of 0.118 mm (1/216 inch) |
| Input Data Buffer | |||
|---|---|---|---|
| 128 KByte |
| Interface | |||
|---|---|---|---|
| STANDARD | Bi-directional parallel interface (IEEE-1284 nibble mode supported) | ||
| Serial I/F | |||
| USB (ver 2.0 full speed) I/F |
| Ribbon Cartridge | |||
|---|---|---|---|
| Standard Fabric Ribbon Cartridge | Colour: Black Type: Fabric Ribbon Life: Approx. 4 million characters (Draft 10 cpi, 14 dots/character) |
| Acoustic Noise | |||
|---|---|---|---|
| Approx. 53dB (A) (ISO 7779 pattern) |
| Reliability | |||
|---|---|---|---|
| MVBF (Mean Print Volume Between Failure) | Approx. 12 million lines (Except print head) | ||
| MTBF (Mean Time Between Failure) | Approx. 10,000 POH (25% duty cycle) | ||
| Print Head Life | Approx. 400 million strokes/wire |
| Control Panel | |||
|---|---|---|---|
| 4 switches, 5 LEDs |
| Environmental Conditions (Operating) | |||
|---|---|---|---|
| Temperature | 5 ~ 35 °C | ||
| Humidity | 10 ~ 80 % RH |
| Electrical Specification | |||
|---|---|---|---|
| Rated Voltage | AC 120 V / AC 220 - 240 V | ||
| Rated Frequency | 50 Hz / 60 Hz | ||
| Power Consumption | Approx. 27 W (ISO/IEC 10561 Letter pattern) Approx. 1.1 W in sleep mode 0 W in powered off mode Approx. 0.3W in auto off mode |
| Dimensions | |||
|---|---|---|---|
| Width | 362 mm (348 mm Except knob) | ||
| Depth | 275 mm | ||
| Height | 154 mm | ||
| Weight | Approx. 4.1 kg |
| Printer Driver / Utility | |||
|---|---|---|---|
| OS | Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®/8/10/11 | ||
| Utility | Epson Status Monitor 3 (Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®/8/10/11) Epson Printer Setting (Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®/8/10/11) |
| Options | |||
|---|---|---|---|
| C13S015637 | Fabric Ribbon Cartridge (Black) | ||
| C11C811141 | Roll Paper Holder |
| Warranty | |||
|---|---|---|---|
| Standard Warranty | Fabric Ribbon Cartridge (Black) | ||
| Optional | Additional 2 years return to base warranty - 3YWLX350 |
| SKU | C11CC24041 |
| Barcode # | 9314020611919 |
| Brand | EPSON |
| Shipping Weight | 5.0000kg |
| Shipping Width | 0.425m |
| Shipping Height | 0.210m |
| Shipping Length | 0.360m |
| Shipping Cubic | 0.032130000m3 |
Manufacturer Warranty: 12 Months Limited Warranty
