Corsair Force Series MP510 960GB NVMe PCIe Gen3 x4 M.2 SSD - CSSD-F960GBMP510B
Model # CSSD-F960GBMP510B
-
SKU: CSSD-F960GBMP510B
- Pick Up Available
- Australian Warranty
- Checkout Securely
Corsair Force MP510 960GB M.2 NVMe SSD CSSD-F960GBMP510B
The Corsair Force MP510 CSSD-F960GBMP510B is a 960GB M.2 2280 NVMe SSD using PCIe Gen 3.0 x4. Supplied data lists up to 3,480MB/s sequential read, up to 3,000MB/s sequential write, 3D TLC NAND, AES 256-bit encryption and a 5-year limited warranty.
Key features
Read up to 3,480MB/s; write up to 3,000MB/s
Read up to 280K IOPS; write up to 700K IOPS
PCIe Gen 3.0 x4; NVMe 1.3
3D TLC NAND; DRAM cache listed as Yes
PS5012-E12
80mm x 22mm x 3.5mm; 0.0082kg
Explore DeviceDeals Storage & Hard Drives guide for broader HDD and SSD buying guidance.
Manufacturer warranty
This product is supplied with a 5-year limited Corsair manufacturer warranty. DeviceDeal is an authorised reseller. Warranty coverage and claims are subject to the manufacturers terms, eligibility requirements and product assessment. Please retain your DeviceDeal tax invoice as proof of purchase.
Frequently asked questions
What capacity is supplied?
The supplied product data lists 960GB capacity.
What sequential speeds are listed?
The supplied data lists up to 3,480MB/s read and up to 3,000MB/s write.
What random performance is listed?
Random read is listed up to 280K IOPS and random write up to 700K IOPS.
What interface and protocol are specified?
The supplied data lists PCIe Gen 3.0 x4 with NVMe 1.3.
What manufacturer warranty is listed?
The supplied data lists a 5-year limited Corsair manufacturer warranty; DeviceDeal is an authorised reseller.
(CSSD-F960GBMP510B)
Features and highlights
Read up to 3,480MB/s; write up to 3,000MB/s
Read up to 280K IOPS; write up to 700K IOPS
PCIe Gen 3.0 x4; NVMe 1.3
3D TLC NAND; DRAM cache listed as Yes
PS5012-E12
80mm x 22mm x 3.5mm; 0.0082kg
Specifications
| Specification | Value |
|---|---|
| Capacity | 960GB |
| Form Factor | M.2 2280 |
| Interface | PCIe Gen 3.0 x4 |
| PCIe Protocol | NVMe 1.3 |
| Controller | PS5012-E12 |
| Software | Corsair SSD Toolbox |
| NAND Type | 3D TLC |
| PCB Form Factor | Double Sided |
| DRAM Cache | YES |
| Sequential Read (CDM) | Up to 3,480MB/s |
| Sequential Write (CDM) | Up to 3,000MB/s |
| 4KB Random Read (QD32) | Up to 280K IOPS |
| 4KB Random Write (QD32) | Up to 700K IOPS |
| MTBF | 1,800,000 Hours |
| Encryption | AES 256-bit Encryption |
| Product Dimensions | 80mm x 22mm x 3.5mm / 3.15' x 0.86' x 0.14' |
| Product Weight | 0.0082kg / 0.18 lbs |
| Warranty | 5 Years Limited Warranty |
| SKU | CSSD-F960GBMP510B |
| Barcode # | 840006623069 |
| Brand | CORSAIR |
| Shipping Weight | 0.0900kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.150m |
| Shipping Cubic | 0.000750000m3 |
Manufacturer warranty
This product is supplied with a 5-year limited Corsair manufacturer warranty. DeviceDeal is an authorised reseller. Warranty coverage and claims are subject to the manufacturers terms, eligibility requirements and product assessment. Please retain your DeviceDeal tax invoice as proof of purchase.
