System Operation System Linux Language Multi-language interface: English, Chinese, Spanish, French, German, Turkish, Russian, Czech, Serbian, Portuguese, Polish, Romanian, Hebrew, Japanese, and Persian Operation Mode Button and keyboard Auto Standby/Shutdown Yes Keyboard Sound Enable/Disable Screen 4.0" TFT screen, 800 × 480 resolution Keyboard Controlling keyboard: 13 keys of the main keyboard, and 45 keys of the flip keyboard Others: Power button, reset button LED Indicator Light 2 * 35lm lights Update Online and local update IPC Test Camera Access ONVIF Resolution 1MP, 1.3MP, 2MP, 3MP, 4MP, 5MP, 6MP, 8MP, and 12MP Camera Initialization Yes Video Display Live view, snapshots, records, digital zoom, and H.264/H.265 decoding Function Control Support IPC modifications such as resolution, IP, and account password, and restoring IPC to factory settings Analog Video Test Format HDCVI, HDTVI, AHD, and CVBS (NTSC, PAL) Resolution HDCVI: 2MP@25 fps/30 fps, 4MP@25 fps/30 fps, 5MP@20 fps, 6MP@20 fps, 4K@12.5 fps/15 fps HDTVI: 2MP@25 fps/30 fps, 4MP@25 fps/30 fps, 5MP@20 fps AHD: 2MP@25 fps/30 fps, 4MP@25 fps/30 fps CVBS: NTSC, PAL Function Control OSD menu display and PTZ control Video Display Live view, snapshots, records, and digital zoom Video Signal Generator Generate PAL and NTSC video test signals Generate HDCVI, HDTVI, and AHD video test signals with 720/1080P RS–485 Control Communication Protocol More than 30 protocols such as Pelco-D/P, Samsung, Panasonic, Lilin, and Yaan Baud Rate 150 bps, 300 bps, 600 bps, 1200 bps, 2400 bps, 4800 bps, 9600 bps, and 19200 bps Protection ESD Air discharge: ±8KV Contact discharge: ±6KV Others Audio Test 1 channel audio input test and 1 channel audio output test Camera Power Supply 12V/2A DC power output to the camera Network Test IP address scanning, and Ping test Voltage Test Display voltage, data transmission, and signal strength of PoE/PSE device Data Monitor Receive and display protocol data with a RS–485 cable Network Cable Test Test the length and attenuation of a network cable Test range: 1–130 m (3.28–426.51 ft) (The maximum length varies depending on the material of the cable) Digital Multimeter Tests of AC/DC voltage, AC/DC current, resistance, capacitance, diode, and circuit conductivity Certifications Certifications CE: EN 55032 FCC: FCC Part 15 Subpart B Port Power 1 standard PoE charging, IEEE802.3af 1 power output , 12V/2A DC Audio 1 audio input 1 audio output USB 1 USB Mini-B Ethernet 2 RJ45 10M/100M/1G RS–485 1 Digital Multimeter Port 3 Power Charging PoE 48V-0.32A Battery Dedicate battery, replaceable, 7.4V polymer lithium ion batteries, up to 22.2Wh, working for about 8 hours Enviroment Operating Temperature –10°C to +55°C (+14°F to +131°F) Operating Humidity 30%–95% (RH) Structure Appearance Color Yellow Dimensions 193.0 × 115.0 × 37.1 mm (7.8" × 4.53"× 1.48") Net Weight 0.54 kg (1.19 lb) Gross Weight 1.40 kg (3.09 lb) newsletter Submit Enter your email address to receive the latest news & products information Cookies Statements Cookies Setting
