Screen Resolution 1024P × 600P Touch Screen Support Backlight LED Brightness Self-adaptive/Manually set Button (Screen on/off) MENU (Menu of screen, include brightness setting and version info) (Volume up) (Volume down) (Mirror setting) F1 (Display main menu of MXVR/MNVR) F2 (Back) Mirror Support Port Video Input 1 channel video input (VGA) Audio Input 1 channel, VGA Audio Output 1 channel, speaker Power Supply Protection Circuit Support, +/- reverse protection Working Voltage 12V DC Power Supply ?6W Structure Installation Method Bracket mounting Dimension 181.4mm × 121.6mm × 27.7mm Cable Length 1 m (5m extension cable is included) Net Weight 450 g Environment Operating Temperature –30°C to +70°C (–22°F to +158°F) Operating Humidity 0%-95%RH (non-condensing)
