Hardware Sold in Pairs Yes Function Slots 1 × RJ-45 10/100/1000 Base-T Power Supply 100 – 240 VAC Power Consumption Full load: 4.5 W Memory DDR 64 MB Indicator Light 1 × PWR light 1 × LAN light 4 × RSSI LEDS Performance Wireless Standard 5 GHz: IEEE 802.11a/n Operating Frequency 5.150 – 5.850 GHz (FCC 5.150 - 5.250 and 5.725 - 5.850 GHz) Wireless Transmission Rate 802.11 n: 300, 270, 240, 180, 120, 90, 60, 30 Mbps 802.11 a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps Channel Width 5/10/20/40 MHz Max. Output Power CE EIRP: ?23 dBm@5150-5250 MHz; ?23 dBm@5250-5350 MHz; ?27 dBm@5470-5725 MHz; ?14 dBm@5725-5850 MHz FCC output power: ?24 dBm@5150-5250 MHz; ?24 dBm@5250-5350 MHz; ?24 dBm@5470-5725 MHz; ?30 dBm@5725-5850 MHz Antenna Direction Angle Horizontal: 30°, vertical: 30° Transmission Distance 3000 m (9842.52 ft) PoE PoE In: 24 V/0.5 A PoE Out: NA Function Operating Mode AP (WDS)/WAP (TDMA2)/WAP(TDMA3)/Station (WDS/TDMA2/TDMA3)/Wireless client (ARPNAT) Equipment Management WEB Encryption Mode WPA/WPA2-Personal; WPA/WPA2-Enterprise Security Mechanism ACL; user isolation OFDMA Yes MU-MIMO 2 × 2 DFS Yes DHCP Yes Firmware Update Web update Software DHCP server; SNMP server; NTP client; router advertisement daemon; ping watchdog General Operating Temperature –30 °C to +70 °C (–22 °F to +158 °F) Storage Temperature –40 °C to +85 °C (–40 °F to +185 °F) Operating Humidity 5%–95% (RH), non-condensing Net Weight 0.2 kg(0.44 lb) Gross Weight 0.4 kg(0.88 lb) Product Dimensions 130 mm × 97 mm × 37 mm (5.11 × 3.81 × 1.45) (L × W × H) Packaging Dimensions 174 mm × 135 mm × 80 mm (6.85 × 5.31 × 3.14)(L × W × H) Protection IP66 Installation Bracket mount Certifications CE; FCC Packing List 1 × Device; 2 × Dowel Pin; 1 × Pole Mount Bracket; 1 × Power Cord; 1 × 24 V PoE Power Adapter; 1 × Quick Start Guide
