System Processor Embedded processor Operating System Embedded LINUX Performance Video Format H.265+/ H.265/ H.264/ MPEG4/ MPEG2/ MJPEG Audio Format PCM/G.711 Decoding Resolution 32MP/12MP/8MP/5MP/3MP/1080P/720P/960H/D1/HD1/2CIF/CIF/QCIF Video Output HDMI/VGA Display Resolution 3840×2160(30fps)/1920×1080/1280×1024/1280×720/1024×768 Audio Output HDMI (embedded) Communication Interface 1 RJ45 network port (10M/100M/1000M, Self-adaptive); 1 RS232(DB9); 1 RS485 Bi-directional Talk 1 channel (reserved), RCA in / RCA out (2Vrms, 10K ohms) Alarm Input 4ch Alarm Output 4ch relay out (30VDC 1A, 125VAC, 0.5A) Others Power Supply DC12V, 3.3A Power Consumption ?20W Working Temperature -10 °C to +55 °C (14 °F to 131 °F) Working Humidity 10~90%RH / 86~106kpa Unit Dimension 1U, 440×322.8×44mm(17.32 × 12.71 × 1.73 inch), (W*D*H) Weight 3.2Kg(7.05 lb)
