Epson ELP-DC13 Document Camera USB HDMI
Model # V12H757053
-
SKU: ELP-DC13
- Pick Up Available
- Australian Warranty
- Checkout Securely
Epson ELP-DC13 Full HD 1080p USB and HDMI Document Camera
A Full HD document camera with 16x digital zoom, HDMI connectivity, a built-in microphone and microscope-adapter support.
Product overview
Flexible Full HD capture for documents, objects and experiments
The Epson ELP-DC13 is designed to capture and display books, 3D objects and experiments at Full HD 1080p resolution. Its supplied 1/2.7-inch CMOS sensor, 16x digital zoom and maximum 297 × 526 mm capture area support detailed views and A3-size pages.
The source describes USB or VGA connection to a PC or Mac, HDMI and VGA connection to a projector, and an SD card slot for opening or saving files. Epson Easy Interactive Tools support split-screen viewing, video recording with audio and image capture.
Product details
Technical specifications
| Supplied product information | |
|---|---|
| Brand | Epson |
| SKU | ELP-DC13 |
| Product code / model | V12H757053 |
| Product type | Document camera |
| Imaging sensor | 1/2.7-inch CMOS |
| Output resolution | Full HD 1080p |
| Frame rate | 30 fps at 1080p |
| Zoom | 16x digital zoom |
| Maximum capture area as supplied | 297 × 526 mm at 1080p |
| Capture-size description | Full A3-size pages; two A4-size documents |
| Connections described | USB; VGA; HDMI |
| Storage | SD card support |
| Microphone | Built in |
| Lighting | Integrated LED lighting system |
| Camera movement | 90° vertical and horizontal rotation |
| Functions described | One-touch autofocus; freeze; capture; split screen; image rotation; source switching |
| Microscope support | Microscope adapter included |
| Software | Epson Easy Interactive Tools identified |
| Security features | Kensington lock; built-in security bar; mounting holes |
| Detailed warranty term | Not supplied in the approved source content |
Helpful answers
Frequently asked questions
What output resolution is supplied?
Full HD 1080p is listed.
Which connections are described?
USB and VGA are listed for PC or Mac connection, while HDMI and VGA are listed for projector connection.
Can it save images or recordings?
Yes. The supplied content describes saving to an SD card or computer.
Is a microscope adapter included?
Yes. A microscope adapter is explicitly identified as included.
(ELP-DC13)
| DOCUMENT CAMERA | |
|---|---|
| PRODUCT NAME | ELP-DC13 Document Camera |
| PRODUCT CODE | V12H757053 |
| CAMERA | |
|---|---|
| Pick-up Device | 1/2.7" CMOS Sensor |
| Effective Pixels | 2MP* |
| Native Resolution | 1080p |
| Aspect Ratio | 16:9 |
| Frame Rate | Maximum 30fps |
| Output Resolution | Analogue: SXGA / XGA / WXGA / 1080p USB : VGA / SVGA / XGA / SXGA / WXGA / 720p / 1080p HDMI : 480p / 720p / 1080p |
| Illumination | White LED x 2 (Variable LED Light) |
| Brightness | 250 lx or above (at A3 shooting area) |
| OPTICS | |
|---|---|
| Lens | Digital Zoom f/2 |
| Shooting Area | Maximum 297 x 526 mm at 1080p output resolution |
| Zoom | 16 x Digital Zoom |
| Illumination | White LED x 2 |
| Focus | Auto |
| FUNCTIONS | |
|---|---|
| White Balance | Yes (Auto) |
| Exposure | Yes (Auto) |
| Brightness Control | Off, Middle, High |
| Image Rotation | Yes |
| Image Freeze | Yes |
| Source Search | Yes |
| Aspect Ratio | Yes (Auto) |
| Digital Scroll Pan/Tilt | Yes |
| Flicker Reduction | Yes (50Hz, 60Hz) |
| Negative/Positive | Yes |
| Colour & Black & White Selection | Yes |
| Split Screen | Yes |
| Time Lapse | Yes |
| Microscope View | Yes |
| SD Card Slot | Yes |
| Still Image Saving Formats & Slideshow |
Capture: JPEG (Resolution: 1920 x 1080) Slideshow : JPEG (Resolution 7680 x 5760) |
| Video Movie Video Capture & Play |
Capture: AVI (Motion JPEG + PCM) Resolution: 720p File size: up to 2GB |
| INTERFACE | |
|---|---|
| Input | VGA, in-built MIC |
| Output | VGA, USB-B, HDMI |
| DIMENSIONS | |
|---|---|
| Dimensions (Open) (DxWxH) | 447 x 270 x 317 mm |
| Dimensions (Closed) (DxWxH) | 120 x 367 x 122 mm |
| Weight | Approx. 2.5kg |
| OTHER | |
|---|---|
| Kensington Lock | Yes |
| Power Supply Voltage | 100 - 240V AC |
| Power Frequency | 50/60Hz |
| Output Voltage of AC Power Adapter | DC 12V |
| Power Consumption | 13W |
| Power Consumption (Standby mode) |
less than 0.5W |
| PC applications* | Easy Interactive Tools Ver 4.11 (for Windows) Easy Interactive Tools Ver 4.10 (for Mac OS X) |
| WHAT'S IN THE BOX | Epson ELPDC13 Document Camera, External AC Power Adaptor with Power Cord, VGA Cable, 3m USB Cable, User's Manual Set CD ROM, Remote Control, 2 x AA Batteries, Microscope Adaptor, Quick Start Guide, Warranty Card |
| WARRANTY | |||
|---|---|---|---|
| Standard Warranty | 12 months | ||
| *N.B. The effective number of pixels is 2.07M (1920x1080p) | |||
| Epson is the registered trademark of Seiko Epson Corporation. Epson ESC/P2 and Epson Stylus are trademarks of Seiko Epson Corporation. MicroDot is a trademark of Epson Australia Pty Limited. All other product names and other company names used herein are for identification purposes only and may be the trademarks or registered trademarks of their respective owners. Epson disclaims any and all rights in those marks. Specifications are subject to change without notice. | |||
| SKU | ELP-DC13 |
| Barcode # | 9314020621079 |
| Brand | EPSON |
| Shipping Weight | 4.4000kg |
| Shipping Width | 0.240m |
| Shipping Height | 0.180m |
| Shipping Length | 0.450m |
| Shipping Cubic | 0.019440000m3 |
