Specifications

Interface

PCIe® 4.0 x4 / 5.0 x2 NVMe™ 2.0

Sequential Read

Up to 5,000 MB/s *

* Performance may vary based on system hardware & configuration

Sequential Write

Up to 4,200 MB/s *

* Performance may vary based on system hardware & configuration

Warranty

5-year Limited Warranty or 600 TBW Limited Warranty

Application

Client PCs

Weight

Max 9.0g Weight

General Feature

Application

Client PCs

Rated Capacity

1,000GB (1GB=1 Billion byte by IDEMA)

* Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

Form Factor

M.2 (2280)

Interface

PCIe® 4.0 x4 / 5.0 x2 NVMe™ 2.0

Dimension (WxHxD)

80 x 22 x 2.38 mm

Weight

Max 9.0g Weight

Storage Memory

Samsung V-NAND TLC

Controller

Samsung in-house Controller

Cache Memory

HMB(Host Memory Buffer)

Special Feature

TRIM Support

Supported

S.M.A.R.T Support

Supported

GC (Garbage Collection)

Auto Garbage Collection Algorithm

Encryption Support

AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)

WWN Support

Not supported

Device Sleep Mode Support

Yes

Performance

Sequential Read

Up to 5,000 MB/s *

Sequential Write

Up to 4,200 MB/s *

Random Read (4KB, QD32)

Up to 680,000 IOPS *

Random Write (4KB, QD32)

Up to 800,000 IOPS *

Random Read (4KB, QD1)

Up to 20,000 IOPS *

Random Write (4KB, QD1)

Up to 90,000 IOPS *

* Performance may vary based on system hardware & configuration

Environment

Average Power Consumption (system level)

Average: Read 4.9 W / Write 4.5 W *

Power Consumption (Idle)

Typical 60 mW *

Power Consumption (Device Sleep)

Typical 5 mW *

Allowable Voltage

3.3 V ± 5 % Allowable voltage

Reliability (MTBF)

1.5 Million Hours Reliability (MTBF)

Operating Temperature

0 - 70°C Operating Temperature

Shock

1,500 G & 0.5 ms (Half sine)

* Actual power consumption may vary depending on system hardware & configuration

Software

Management SW

Magician Software for SSD management

Warranty

5-Year Limited Warranty or 600 TBW Limited Warranty

Manufacturer Warranty : 5 years Manufacturer Warranty
