System(VTO)

Main Processor

Embedded Processor

Operating System

Embedded Linux Operation System

Button Type

Mechanical

Interoperability

ONVIF; CGI

Network Protocol

SIP; TCP; RTP; UPnP; P2P; DNS; UDP; RTSP; IPv4

Basic(VTO)

Camera

1/2.9" 2 MP CMOS

Field of View

H: 168.6°; V: 87.1°; D: 176.7°

WDR

120 dB

Noise Reduction

3D NR

Video Compression

H.265; H.264

Video Resolution

Main stream: 720p; WVGA; D1; CIF
Sub stream: 1080p; WVGA; D1; QVGA; CIF

Video Frame Rate

25 fps

Video Bit Rate

256 kbps to 8 Mbps

Light Compensation

Auto IR

Day/Night

Auto(ICR)/Color/B/W; Color/B/W

Audio Compression

G.711a; G.711u; PCM

Audio Input

1 channel

Audio Output

Built-in speaker

Audio Mode

Two-way audio

Audio Enhancement

Echo suppression/digital noise reduction

Audio Bit Rate

16 kHz, 16 bits

Function(VTO)

Communication Mode

Digital 2-wire

Unlock Mode

Remote

Leave Videos

Yes (SD card is inserted in the indoor monitor or door station)

Storage

Supports Micro SD card (up to 256 GB)

Web Configuration

Yes

Performance(VTO)

Casing Material

Aluminum

Port(VTO)

RS-485

1

Alarm Output

1

Power Output

1 port (12 V, 600 mA)

Exit Button

1

Door Status Detection

1

Lock Control

1

Network Port

1 × RJ-45 port, 10/100 Mbps network port

Alarm(VTO)

Tamper Alarm

Yes

General(VTO)

Appearance Color

Silver

Power Supply

Dahua 2-wire switch (max. power supply distance is 50 m)
48 VDC, 1 A; PoE (802.3af/at)

Power Adapter

Optional

Installation

Surface mount (The surface mount kit comes with the surface mount bracket)

Certifications

CE

Accessory

Surface mount box (included)

Product Dimensions

130 mm × 96 mm × 28.5 mm (5.12" × 3.78" × 1.12")

Protection

IK07; IP65

Operating Temperature

–30 °C to +60 °C (–22 °F to +140 °F)

Operating Humidity

10%–90% (RH), non-condensing

Operating Altitude

0 m–3,000 m (0 ft–9,842.52 ft)

Operating Environment

Outdoor

Power Consumption

≤4 W (standby), ≤5 W (working)

Gross Weight

0.48 kg (1.06 lb)

Storage Humidity

30%–75% (RH), non-condensing

Storage Temperature

0 °C to +40 °C (+32 °F to +104 °F)

System (VTH)

Main Processor

Embedded Processor

Operating System

Embedded Linux Operation System

Button Type

Touch button

Interoperability

ONVIF

Network Protocol

SIP; IPv4; RTSP; RTP; TCP; UDP

Basic (VTH)

Screen Type

Capacitive Touchscreen

Display Screen

7" TFT

Screen Resolution

1024 (H) × 600 (V)

Audio Compression

G.711a; G.711u; PCM

Audio Input

1

Audio Output

Built-in speaker

Audio Mode

Two-way audio

Audio Enhancement

Echo suppression

Audio Bit Rate

16 kHz, 16 bits

Function (VTH)

Communication Mode

Digital 2-wire

Information Release

Supports viewing text announcement from the center (insert an SD card to receive and view pictures)

Leave Videos

Yes (SD card inserted in VTH is needed)

DND Mode

Do not disturb period can be set;Do not disturb mode can be set

Number of Extensions

Villa: 4; apartment: 3

Storage

Supports Micro SD card (up to 64 GB)

Port (VTH)

RS-485

1

Alarm Input

6 channel (switch quantity)

Alarm Output

1 channel

Power Output

1 port (12 V, 100 mA)

Door Bell

Yes, reusing any alarm input port

Network Port

One 2-wire port and one 10/100 Mbps
Ethernet port (one of them can be selected)

Performance(VTH)

Casing Material

PC + ABS

General (VTH)

Appearance Color

White

Power Supply

2-wire switch (max power transmission distance: 50 m); Standard PoE

Power Adapter

Optional

Installation

Surface Mount

Certifications

CE; FCC; UL

Accessory

Bracket (standard)
Alarm ribbon cable (standard)

Product Dimensions

189.0 mm × 130.0 mm × 26.9 mm (7.44" × 5.12" × 1.06")

Operating Temperature

–10°C to +55°C (+14°F to +131°F)

Operating Humidity

10%–95% (RH), non-condensing

Operating Altitude

0 m–3,000 m (0 ft–9,842.52 ft)

Operating Environment

Indoor

Power Consumption

≤2 W (standby), ≤6 W (working)

Gross Weight

0.74 kg (1.63 lb)

Storage Temperature

0 °C to +40 °C (+32 °F to +104 °F)

Storage Humidity

30%–75% (RH), non-condensing

System(Networking Device)

Main Processor

Embedded Processor

Function(Networking Device)

Communication Mode

Digital 2-wire

Performance(Networking Device)

Casing Material

PC + ABS

Port(Networking Device)

Network Port

1 × 2-wire port; 1 × 100 Mbps Ethernet port

General (Networking Device)

Appearance Color

White

Power Supply

DC 48V 1A–3A

Power Adapter

Included

Installation

Guide Rail Mount

Certifications

CE; FCC; UL

Product Dimensions

131 mm × 103 mm × 40 mm (5.16" × 4.06" × 1.57")

Operating Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

10%–95% (RH), non-condensing

Operating Altitude

0 m–3,000 m (0 ft–9,842.52 ft)

Power Consumption

≤15 W (self-working); output≤48 W (villa)

Gross Weight

0.39 kg (0.86 lb)
