TP-LINK ARCHER D5 AC1200 Wireless Dual Band Gigabit ADSL2+ Modem Router

ArcherD5

8-Port 10/100Mbps Desktop Switch with 4-Port PoE TL-SF1008P With four PoE ports, transfers data and power on one single cable Working with IEEE 802.3af compliant PDs, expands home and office network Requires no configuration and installation

(ArcherD5)

Supports 802.11ac standard - the next generation of Wi-Fi
Simultaneous 2.4GHz 300Mbps and 5GHz 867Mbps connections provide a premium wireless experience
Share a printer locally and files & media with networked devices or remotely via FTP server.
Ethernet WAN (EWAN) port accepts connections from cable and fiber modems via Ethernet cable
New web UI and Tether APP provide quick & hassle-free installation and easy management

HARDWARE FEATURES
Interface	1 10/100/1000Mbps RJ45 WAN/LAN Port 3 10/100/1000Mbps RJ45 LAN Ports 1 RJ11 Port 2 USB 2.0 Ports
Button	1 Power On/Off Button 1 Wi-Fi On/Off Button 1 WPS Button 1 RESET Button
Power Supply	12VDC/2.5A
IEEE Standards	IEEE 802.3, 802.3u, 802.3ab
ADSL Standards	Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite) ITU-T G.994.1 (G.hs), ITU-T G.995.1
ADSL2 Standards	ITU-T G.992.3 (G.DMT.bis), ITU-T G.992.4 (G.lite.bis)
ADSL2+ Standards	ITU-T G.992.5
Dimensions ( W x D x H )	9.0 x 6.3 x 1.5 in. (229 x 160 x 37mm)
Antenna Type	Detachable dual band external antennas
Antenna Gain	2dBi for 2.4GHz and 3dBi for 5GHz

WIRELESS FEATURES
Wireless Standards	IEEE 802.11ac/n/a 5GHz IEEE 802.11n/g/b 2.4GHz
Wireless Speeds	5GHz: Up to 867Mbps 2.4GHz: Up to 300Mbps
Frequency	2.4GHz and 5GHz
Transmit Power	<20dBm(EIRP)
Wireless Functions	Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption, Wireless MAC Filtering
Wireless Schedule	Support 2.4GHz and 5GHz Wireless Schedule

SOFTWARE FEATURES
Quality of Service	ATM QoS, Bandwidth Control
Security	NAT Firewall, Access Control, MAC / IP / URL Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death IP and MAC Address Binding
IPv6	IPv6 and IPv4 dual stack
Operating Modes	ADSL Modem Router, Wireless Router
Management	Web Based Configuration(HTTP), Remote management, Command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools
DHCP	Server, Client, DHCP Client List, Address Reservation, DHCP relay
Port Forwarding	Virtual server, Port Triggering, DMZ, ALG, UPnP
Dynamic DNS	DynDns, NO-IP
VPN	PPTP, L2TP, IPSec Passthrough
ATM Features	ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed) Bridge (RFC1483 Bridge) PVC – Up to 8 PVCs
Advanced Functions	Parental Control Network Address Translation (NAT); Port Mapping (Grouping), Static Routing, RIP v1/v2 (optional); DNS Relay, DDNS, IGMP V1/V2/V3
USB Sharing	Support Samba(Storage)/FTP Server/Media Server/Printer Server
Guest Network	2.4GHz guest network × 1 5GHz guest network × 1
IPSec VPN	Supports up to 10 IPSec VPN tunnels

OTHERS
Certification	CE, FCC, RCM, RoHS
Package Contents	AC1200 Wireless Dual Band Gigabit ADSL2+ Modem Router External Splitter RJ-11 Telephone Cable RJ-45 Ethernet Cable Quick Installation Guide Power Adapter
System Requirements	Windows 10/8/7/Vista/XP or Mac OS or Linux-based operating system
Environment	Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing

SKU	ArcherD5
Barcode #	845973050986
Brand	TP-Link
Shipping Weight	1.0000kg
Shipping Width	0.320m
Shipping Height	0.070m
Shipping Length	0.240m
Shipping Cubic	0.005376000m3

Manufacturer Warranty: 3 Years Limited Warranty
Manufacturer Contact Info: http://www.tp-link.com.au
1300 875 465
