Zebra MC3401-0G1J54SS-A6 Rugged Handheld Mobile Computer

ZebraSKU MC3401-0G1J54SS-A6Rugged Handheld Mobile Computer

Zebra MC3401-0G1J54SS-A6 MC3400 Gun Mobile Computer - SE4770, 47-Key

The Zebra MC3401-0G1J54SS-A6 is a Rest-of-World MC3400 WLAN gun mobile computer with an SE4770 1D/2D imager, 47-key alphanumeric keypad, 4-inch 600-nit display, Android GMS, 6GB/64GB memory and a standard 7,000mAh battery.

Key features

SE4770 Data Capture

The integrated SE4770 captures 1D and 2D barcodes and is positioned by Zebra for indoor and outdoor scanning workflows.

Key-Driven Gun Design

A pistol-grip gun form factor and 47-key alphanumeric keypad support scan-intensive warehouse data entry, including gloved operation.

Modern WLAN Performance

Tri-band Wi-Fi 6E with 2x2 MU-MIMO, Bluetooth 5.3 BLE and NFC connect the device to enterprise networks and supported peripherals.

Rugged Full-Shift Platform

A 7,000mAh standard battery, dual IP65/IP67 sealing and Zebra's drop and tumble specifications support demanding daily operations.

What to know

MC3400 WLAN-only gun form factor
SE4770 1D/2D imager for indoor and outdoor scanning
47-key alphanumeric keypad
4-inch WVGA 800 x 480 display at 600 nits
6GB RAM and 64GB UFS flash
Wi-Fi 6E, Bluetooth 5.3 BLE and NFC
7,000mAh standard rechargeable battery

Australian supply and warranty

This Australian version is supplied by DeviceDeal and is covered by the Zebra 1-year zebra limited hardware against defects in workmanship and materials for one year from shipment subject to zebra's hardware terms and applicable australian consumer law. manufacturer warranty in Australia. Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to Zebra warranty terms, eligibility requirements and product assessment.

Frequently asked questions

Which scanner is built into MC3401-0G1J54SS-A6?

This exact configuration has Zebra's SE4770 1D/2D imager, positioned for indoor and outdoor barcode capture.

Does this MC3400 have cellular connectivity?

No. The MC3400 is the WLAN-only model and this configuration uses Wi-Fi 6E; the MC3450 is the cellular-capable model in the family.

Which keypad and memory configuration are included?

It includes the 47-key alphanumeric keypad, 6GB RAM and 64GB UFS flash storage.

What battery is supplied?

The source specifies the standard rechargeable 7,000mAh battery rather than the optional BLE-beacon battery.

What is the main difference from MC3401-0G1M54SS-A6?

This J-coded configuration uses the SE4770 imager for general indoor/outdoor scanning; MC3401-0G1M54SS-A6 uses the extended-range SE58 engine.

What warranty applies to the Zebra MC3401-0G1J54SS-A6?

(MC3401-0G1J54SS-A6)

Features and highlights

Zebra MC3401-0G1J54SS-A6 MC3400 Gun Mobile Computer - SE4770, 47-Key

SE4770 Data Capture

The integrated SE4770 captures 1D and 2D barcodes and is positioned by Zebra for indoor and outdoor scanning workflows.

Key-Driven Gun Design

A pistol-grip gun form factor and 47-key alphanumeric keypad support scan-intensive warehouse data entry, including gloved operation.

Modern WLAN Performance

Tri-band Wi-Fi 6E with 2x2 MU-MIMO, Bluetooth 5.3 BLE and NFC connect the device to enterprise networks and supported peripherals.

Rugged Full-Shift Platform

A 7,000mAh standard battery, dual IP65/IP67 sealing and Zebra's drop and tumble specifications support demanding daily operations.

Key highlights

MC3400 WLAN-only gun form factor
SE4770 1D/2D imager for indoor and outdoor scanning
47-key alphanumeric keypad
4-inch WVGA 800 x 480 display at 600 nits
6GB RAM and 64GB UFS flash
Wi-Fi 6E, Bluetooth 5.3 BLE and NFC
7,000mAh standard rechargeable battery
Dual IP65/IP67 sealing and haptic feedback

Warranty confidence

1-year zebra limited hardware against defects in workmanship and materials for one year from shipment subject to zebra's hardware terms and applicable australian consumer law. manufacturer warranty in Australia.

Zebra MC3401-0G1J54SS-A6

Technical specifications

Zebra MC3401-0G1J54SS-A6 MC3400 Gun Mobile Computer - SE4770, 47-Key

Product

Brand	Zebra
Model	MC3401-0G1J54SS-A6
SKU	MC3401-0G1J54SS-A6
Product Type	Rugged Handheld Mobile Computer

Configuration

Series / Model	MC3400 expanded-tier gun
Region	Rest of World (ROW)
Cellular	No; MC3400 is WLAN-only

Operating System

Platform	Android with Google Mobile Services (GMS)

Performance

Processor	Qualcomm 4490 octa-core, 2.4 GHz
Memory	6 GB RAM
Internal Storage	64 GB UFS flash
Expansion	microSD support up to 2 TB

Display

Panel	4.0-inch WVGA (800 x 480) colour display, 600 nits

Input

Keypad	47-key alphanumeric
Notifications	Audible tone, two multicolour LEDs and haptic/vibrator feedback

Data Capture

Scan Engine	SE4770 1D/2D imager
Intended Scanning	Indoor and outdoor barcode capture

Camera

Integrated Camera	No; Zebra's MC3400 expanded-tier configuration table specifies no camera

Wireless

WLAN	Wi-Fi 6E, tri-band 2.4/5/6 GHz, 2x2 MU-MIMO
Bluetooth	Bluetooth 5.3 with Bluetooth Low Energy
NFC	Yes

Battery

Included Configuration	Standard rechargeable Li-ion, 3.6 V, 7,000 mAh (25.20 Wh)

Ports

USB	USB 2.0 High Speed host/client through bottom pogo and side USB-C connections

Physical

Dimensions	208.5 x 73.5 x 165.3 mm (gun model)
Device Weight	528 g (gun model)

Ruggedness

Ingress Protection	IP65 and IP67 with battery installed
Drop Specification	2.4 m (8 ft) to concrete at room temperature; 1.8 m (6 ft) across the operating-temperature range
Tumble Specification	4,000 tumbles at 1 m (3.3 ft)

Package

Width	0.175 m
Length	0.22 m
Height	0.09 m
Shipping Weight	0.65 kg
Cubic Volume	0.003465 m³

Warranty

Warranty	1-year zebra limited hardware against defects in workmanship and materials for one year from shipment subject to zebra's hardware terms and applicable australian consumer law. manufacturer warranty in Australia

SKU	MC3401-0G1J54SS-A6
Brand	Zebra
Shipping Weight	0.6500kg
Shipping Width	0.175m
Shipping Height	0.090m
Shipping Length	0.220m
Shipping Cubic	0.003465000m3
