Port Alarm Output 2 Alarm Iutput 8 RS-485 1, connected to a maximum of 300 m ( 984.25 ft ) cable typed RVV2*1.5 Function Device Address 0–15( ARC9 series, ARC2 series ) 1–8( ARC3008 ) Zone Terminations NC, NO, 1EOL, 2EOL, 3EOL, INERTIAL(ARC3008), and IMPULSE(ARC3008) EOLR 2K7, 4K7, and 6K8 Alarm Output Mode Switch between NO and NC with jumper Output Capacity 30 VDC/500 mA Update Remote update by client software General Power Supply 12 VDC Power Consumption 1.2 W Operating Temperature –10°C to +55°C (+ 14°F to + 131°F) Operating Humidity 10%–90% ( RH ) Product Dimensions 90.0 mm × 62.0 mm × 12.6 mm ( 3.54" × 2.44" × 0.5" ) ( L × W × H ) Net Weight ?1 kg ( 2.20 lb )
