Installation Guide

Overview

Dimensions

Without mount: 90 x 52 x 31 mm (3.5 x 2.1 x 1.2") With mount: 92.1 x 56.3 x 40.8 mm (3.6 x 2.1 x 1.4")

UniFi Application Suite

Connect

Yes

Display Output

(1) HDMI port

NDAA Compliant

Yes

Mechanical

Weight

Without mount: 160 g (5.6 oz) With mount: 180 g (6.3 oz)

Pole Mount Diameter

1~2" (25–50 mm)

Hardware

Processor

Quad-Core Arm® Cortex®-A55, 1.9 GHz

Memory

Storage: 16 GB RAM: 2 GB

Power Method

USB-C 5V DC, 1A

Max. Power Consumption

5W

Connectivity

WiFi 2.4G, BW 20/40 MHz WiFi 5G, BW 20/40/80 MHz

WiFi Standards

802.11 a/b/g/n/ac/ax

Buttons

(1) Factory-reset

LEDs

System

White/blue (Learn More )

Ambient Operating Temperature

0 to 40° C (32 to 104° F)

Ambient Operating Humidity

20 to 90% noncondensing

Certifications

CE, FCC, IC, Wi-Fi CERTIFIED

Software

Management Application

UniFi Connect Web

Version 3.17.0 and later

UniFi Connect iOS™ and Android™

Version 2.26.0 and later

Manufacturer Warranty : 1 Year Manufacturer Warranty
