Solar Panel Type Monocrystalline silicon Max. Power 120W Solar Cell Efficiency 21% Max. Mechanical Load 5400Pa Protection Over-discharge Protection Voltage 11.1V DC Low Temperature Charging ?–10°C (14°F) Low Temperature Discharging ?–20°C (–4°F) Grade IP66 Others Over temperature, overvoltage of the battery, overload, and short circuit Port Power Output ?5.5 mm × ?2.1 mm × 12mm (?0.22" × ?0.08" × 0.47") RS–485 to Ethernet 1 Network 1 RJ–45 1 non-standard PoE General Main Body Material Die casting aluminum Installation Pole mount, installed on 76 mm to 96 mm (?3.0"–?3.78") poles Adjustable Angle Horizontal: 0°–360° Vertical: -75°–80° Product Dimensions 1149.5 mm × 670.0 mm × 455.2 mm (45.26" × 26.38" × 17.92") Packaging Dimensions 1351 mm × 796 mm × 378 mm (53.19" × 31.33" × 14.88") Packaging Method 1 pc in each carton Net Weight 23.5 kg (51.81 lb) Gross Weight 33 kg (72.75 lb) Environment Operating Altitude <3000 m (9842.5 ft) Applicable Area Areas with daily solar radiation >4.5 h Operating Temperature –20°C to 60°C (–4°F to 140°F) Operating Humidity <95% (RH) Storage Temperature 0°C to 40°C (32°F to 104°F) Storage Humidity <95% (RH) Certification Certifications CE: EN61000-6-2, EN61000-6-4 FCC: FCC Part 15 Subpart B

Manufacturer Warranty
