WD_BLACK SN7100 | WDS100T4X0E

Western Digital WD_BLACK SN7100 1TB PCIe 4.0 NVMe M.2 SSD WDS100T4X0E

A WD_BLACK SN7100 gaming NVMe SSD listed as 1TB, with PCIe 4.0, M.2 2280 format and supplied speeds up to 7,250MB/s read and 6,900MB/s write.

1TB Product ListingPCIe 4.07,250MB/s ReadM.2 2280

Western Digital WD_BLACK SN7100 1TB PCIe 4.0 NVMe M.2 SSD WDS100T4X0E

7,250MB/s read

Supplied maximum read performance for the 1TB2TB models.

6,900MB/s write

Supplied maximum write performance for the 1TB2TB models.

TLC 3D NAND

Sandisk next-generation TLC 3D NAND is identified in the supplied description.

5.8g

Weight listed in the supplied structured specifications.

Compare HDD and SSD storage

Explore DeviceDeal storage options, capacities and form factors in one place.

View storage and hard drives

Product overview

The supplied description presents WDS100T4X0E as a WD_BLACK SN7100 NVMe SSD designed with laptops and handheld gaming devices in mind. It uses a PCIe Gen4 interface and is described as a DRAM-less drive using Sandisk next-generation TLC 3D NAND.

The structured specifications identify an M.2 2280 format measuring 22mm x 80mm x 1mm, a weight of 5.8g, an operating temperature range of 085°C and a storage temperature range of -4085°C. The downloadable SANDISK Dashboard is listed for Windows.

Source information to confirm

The product name identifies 1TB, while the structured specification lists 1.02TB. Both supplied values are retained and require confirmation.

Random read and write performance are supplied as 1,000 IOPS and 1,400 IOPS. These unusual values are preserved exactly and no missing multiplier has been inferred.

The 2,400TBW endurance statement applies specifically to the 4TB model and was not applied to this 1TB SKU.

Manufacturer warranty and authorised reseller

The applicable Western Digital manufacturer warranty applies to WDS100T4X0E. An exact warranty duration was not included in the supplied information, so no term has been inferred. DeviceDeal is an authorised reseller. Keep your DeviceDeal tax invoice as proof of purchase; warranty coverage and claims remain subject to Western Digital terms, eligibility requirements and product assessment.

Frequently asked questions

What is the WDS100T4X0E?

It is a WD_BLACK SN7100 PCIe 4.0 NVMe SSD in an M.2 2280 format, listed as a 1TB product.

What capacity is supplied?

The product name lists 1TB, while the structured specification lists 1.02TB. The difference requires confirmation.

What sequential speeds are listed?

The supplied figures are up to 7,250MB/s read and 6,900MB/s write for the 1TB2TB models.

What interface and form factor does it use?

The supplied information lists PCI Express 4.0, NVMe and an M.2 2280 form factor.

What NAND and drive design are identified?

The description identifies Sandisk next-generation TLC 3D NAND and describes the drive as DRAM-less.

What physical and temperature details are supplied?

The specifications list 22mm x 80mm x 1mm, 5.8g, 085°C operating temperature and -4085°C storage temperature.

What random performance is listed?

The source lists 1,000 random-read IOPS and 1,400 random-write IOPS. The formatting is preserved and requires confirmation.

What warranty applies?

The product is supplied with the applicable Western Digital manufacturer warranty, but an exact duration was not included. DeviceDeal is an authorised reseller.

(WDS100T4X0E)

Features and highlights

Western Digital WD_BLACK SN7100 1TB PCIe 4.0 NVMe M.2 SSD WDS100T4X0E exact source-supported highlights.

1TB product listing

The exact product name identifies a 1TB WD_BLACK SN7100 SSD.

PCIe 4.0 NVMe

The supplied interface is PCI Express 4.0 and NVMe is listed as supported.

Up to 7,250MB/s read

This is the supplied maximum read performance for the 1TB2TB models.

Up to 6,900MB/s write

This is the supplied maximum write performance for the 1TB2TB models.

M.2 2280 format

The structured specifications list 2280 size with 22mm x 80mm dimensions.

TLC 3D NAND

The supplied description identifies Sandisk next-generation TLC 3D NAND and a DRAM-less design.

Technical specifications

WDS100T4X0E

Product details

Brand	Western Digital
Product line	WD_BLACK SN7100
DeviceDeal SKU	WDS100T4X0E
Capacity	1TB in product name; 1.02TB in structured specification (requires confirmation)
Product type	NVMe SSD
SSD form factor	M.2
M.2 size	2280 (22 x 80 mm)
Component for	PC/Game console (as supplied; no specific console compatibility list supplied)

Interface and performance

Interface	PCI Express 4.0
NVMe	Yes
Read speed	7250 MB/s
Write speed	6900 MB/s
Random read (4KB)	1000 IOPS (as supplied; requires confirmation)
Random write (4KB)	1400 IOPS (as supplied; requires confirmation)

Design and physical

NAND	Sandisk next-generation TLC 3D NAND
Drive design	DRAM-less
Width	22 mm
Depth	80 mm
Height	1 mm
Weight	5.8 g

Environmental

Operating temperature	085°C
Storage temperature	-4085°C

Warranty

Manufacturer warranty

Applicable Western Digital manufacturer warranty; exact duration not supplied

SKU	WDS100T4X0E
Barcode #	718037893204
Brand	WESTERN DIGITAL
Shipping Weight	0.3000kg
Shipping Width	0.120m
Shipping Height	0.050m
Shipping Length	0.100m
Shipping Cubic	0.000600000m3

Manufacturer Warranty

Manufacturer warranty

WDS100T4X0E is supplied with the applicable Western Digital manufacturer warranty. An exact warranty duration was not included in the supplied product information, so no term has been inferred.

DeviceDeal is an authorised reseller. Keep your DeviceDeal tax invoice as proof of purchase.

Warranty coverage and claims remain subject to Western Digital warranty terms, eligibility requirements and product assessment.
