Camera Image Sensor 1/2.8" CMOS Pixel 4 MP Max. Resolution 2560 (H) × 1440 (V) ROM 4 GB RAM 1 GB Electronic Shutter Speed 1 s–1/30,000 s Scanning System Progressive Min. Illumination 0.005 lux@F1.6 (Color, 30 IRE); 0.0005 lux@F1.6 (B/W, 30 IRE); 0 lux (illuminator on) Illumination Distance 150 m (492.13 ft) (IR); 50 m (164.04 ft) (white light) Illuminator On/Off Control Zoom Prio; Manual; Auto; Off Illuminator Number 2 (IR light); 2 (dual light fusion) Lens Focal Length 4.8 mm–154 mm Max. Aperture F1.6–F4.0 Field of View H: 55.8°–2.3°; V: 31.9°–1.3°; D: 63.7°–2.7° Optical Zoom 32× Focus Control Auto; semi-auto; manual Close Focus Distance 0.1 m–1.5 m (0.33 ft–4.92 ft) Iris Control Auto; manual DORI Distance Detect Observe Recognize Identify 3,080 m (10104.99 ft) 1,216.6 m (3991.47 ft) 616 m (2021.00 ft) 308 m (1010.50 ft) PTZ Pan/Tilt Range Pan: 0° to 360° endless Tilt: –20° to +90°, auto flip 180° Manual Control Speed Pan: 0.1°/s–160°/s; Tilt: 0.1°/s–120°/s Preset Speed Pan: 240°/s; Tilt: 150°/s Preset 300 Tour 8 (up to 32 presets per tour) Pattern 5 Scan 5 Power-off Memory Yes Idle Motion Pattern; Preset; Scan; Tour Intelligence Video Metadata Detects motor and non-motor vehicles, faces and human bodies. It also performs tracking, takes snapshots, uploads high-quality face images and optimizes images. It extracts attributes from motor vehicles, detecting up to 10 attributes for them. IVS (Perimeter Protection) Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human alarm classification; linkage tracking Face Detection Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images. Attribute Extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots. Construction Detection Detects 6 helmet colors: Red, orange, yellow, blue, white, and black. An alarm will be triggered when a person is not wearing a helmet or when the color of the helmet that they are wearing does not match the configured color. It also supports compliance detection for work uniforms. Up to 5 work uniform sample libraries can be uploaded, which together can contain up to 1,000 images (the images must be 1080p and in the JPG format). An alarm will be triggered when the similarity between the detected work uniform and the samples in the library is below the set threshold (that is, below the minimum compliance standard for work uniforms). The system supports detecting the attributes of work uniforms such as the color of the uniform, and whether or not the person is wearing a mask and wearing shoe covers. An alarm will be triggered when the target is detected as not meeting the set requirements. It also detects and triggers alarms when only one person is in the construction site, and when no one is present in the detection area such as when a worker leaves their post or an area is left unmanned. Auto Tracking Auto tracking 3.0 SMD SMD4.0 Acupick Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets. Auto Patrol It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets. Active Deterrence Light Warning Red-Blue light warning Flash duration: 5 s–30 s Flash frequency: High, medium, low Sound Warning Sound warning alarm: Customizable Volume: Volume: 0-100 Alarm duration: 5 s–30 s Video Video Compression H.264H; H.264B; Smart H.265+; H.264; H.265; Smart H.264+; MJPEG (Sub Stream 1) Streaming Capability 3 streams Resolution 4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); 1.3M (1280 × 960); D1 (704 × 576/704 × 480); VGA (640×480); CIF(352×288/352×240) Video Frame Rate Main stream: 4M/3M/2304 × 1296/1080p/1.3M/720p @(1–25/30 fps) Sub stream 1: D1/VGA/CIF@ (1–25/30 fps) Sub stream 2: 1080p/1.3M/720p/CIF @(1–25/30 fps) Bit Rate Control CBR/VBR Video Bit Rate H.264: 96 Kbps–14,848 Kbps H.265: 38 Kbps–8,960 Kbps Day/Night Auto (ICR); Color/B/W BLC Yes WDR 120 dB HLC Yes White Balance Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp Gain Control Auto; manual Noise Reduction 2D NR; 3D NR Motion Detection Yes Region of Interest (RoI) Yes Image Stabilization Electronic Image Stabilization (EIS) Defog Electronic Digital Zoom 16× Image Rotation 180° Privacy Masking Up to 24 areas can be set, with up to 8 areas in the same view; Multiple colors available S/N Ratio ?55 dB Audio Audio Compression PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 Network Network Port RJ-45 (10/100 Base-T) Wireless Carrier Frequency Band LTE-FDD: Seven-Band B1/3/5/7/8/20/28 LTE-TDD: Tri-Band 38/40/41 WCDMA: Tri-Band 1/5/8 GSM: Band3/5/8 Power Transmission CE: 4G: Power class3: 23 dBm ± 2.7 dB 3G: Power class3: 24 dBm + 1/-3 dB 2G: Power class0: 30 dBm ± 2 dB (GSM1800/1900) Power class5: 33 dBm ± 2 dB (GSM850/900) Network Protocol FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RTP;802.1x;QoS;HTTPS;SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;UDP;IGMP;HTTP;SSL;DHCP;SMTP;RTSP;ARP Interoperability ONVIF (Profile S & Profile G & Profile T); CGI; SDK Streaming Method Unicast; Multicast User/Host 20 (total bandwidth: 64 M) Storage Micro SD card (512 GB); FTP/SFTP; NAS Browser IE 9 and later versions; Chrome 41 and later versions; Firefox 50 and later versions; Safari 10 and later versions Management Software DMSS; DSS Pro Mobile Client iOS; Android Port RS-485 1 (baud rate: 1200 bps–9600 bps) Audio Input 1 channel (LINE IN, bare wire) Audio Output 1 channel (LINE OUT,bare wire; built-in speaker (mutually exclusive) Alarm Input 2 (on-off value input: 0–5 VDC) Alarm Output 1 channel Alarm Linkage Capture; recording; send email; preset; tour; pattern; alarm digital output; audio; warning light Alarm Event Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection Power Power Supply 12 VDC, 4 A (–10% to +25%) Power Consumption Deep sleep: 0.12 W Light sleep: 2.64W Basic: 7 W (not pulling stream in 4G); 8 W (pulling stream in 4G); Basic: 11 W (illuminator + not pulling stream in 4G), 12 W (illuminator + pulling stream in 4G) Max: 18 W (illuminator + red and blue alarm lights + speaker + 4G + PTZ) Environment Operating Temperature –40 °C to +70 °C (–40 °F to +158 °F) Operating Humidity ? 95% Protection IP66; TVS 6000 V lightning proof; surge protection; voltage transient protection Structure Product Dimensions 325.0 mm × ?211.0 mm (12.80" × ?8.31") Net Weight 4.2 kg (9.26 lb) Gross Weight 6.7 kg (14.77 lb)
