Camera Image Sensor 1/2.8" CMOS Pixel 4 MP Max. Resolution 2560 (H) × 1440 (V) ROM 128 MB RAM 256 MB Electronic Shutter Speed 1/3s–1/30,000s Scanning System Progressive Min. Illumination Color: 0.05 lux@F1.6 B/W: 0.005 lux@F1.6 0 lux@F1.6 (Illuminator on) Illumination Distance 30 m (98.43 ft) (IR) 30 m (98.43 ft) (white light) Illuminator On/Off Control Manual; Smart IR; Off Illuminator Number 2 (IR) 2 (white light) PIR Sensor Distance 10 m (the height of device is 2.2 m, placed horizontally,+25°C,+77°F) 7m (the height of the device is 2.2 m, placed at an angle of 15° from the horizontal,+25°C,+77°F) Battery Battery Type Lithium-ion Capacity 10 Ah Max. Charging Voltage 4.2 V Operating Temperature 0 °C to +50 °C (+32 °F to +122 °F) Battery Voltage 3.6 V Cycle Lifetime Sleep Mode:7 days (at the rate of 1-hour remote live view per day) Battery Life More than 500 cycles Battery Weight Approx. 192 g (0.42 lb) Solar Module Maximum Power 5.5 W Cell type Monocrystalline Operating Temperature –40 °C to +80 °C (–40 °F to +176 °F) Dimensions 224 mm × 195 mm × 44 mm (8.8" × 5.9" × 1.7") (L × W × H) Standard testing condition AM = 1.5, 25 °C (77 °F), 1000 W/m², SMQ + 12% Lens Focal Length 4mm Max. Aperture F1.6 Field of View H: 84° V: 42° D: 101° Close Focus Distance 2 m (6.56 ft) Iris Control Fixed Iris DORI Distance Detect Observe Recognize Identify 86 m (282.15 ft) 34.4 m (112.86 ft) 17.2 m (56.43 ft? 8.6 m (28.22 ft) PTZ Pan/Tilt Range Pan: 0° to 345° Tilt: 0° to +80° Manual Control Speed Pan: 0.1°/s–74°/s Tilt: 0.1°/s–36.4°/s Preset Speed Pan: 74°/s; Tilt: 36.4°/s Preset 300 Power-off Memory Yes Idle Motion Preset Active Deterrence Light Warning White light warning Flash duration: 5 s–30 s Flash frequency: High, medium, low Sound Warning 1 sound warning alarm The alarm can be configured to go off 1-3 times Video Video Compression H.265; H.264; H.264B; H.264H; MJPEG(Sub Stream) Streaming Capability 2 streams Resolution 4M (2560 × 1440); 1080p (1920 × 1080); 1.3M(1280 × 960); 720p (1280×720); D1 (704 × 576); CIF (352 × 288); VGA (640 × 480) Video Frame Rate Main stream: 4M/1080p/1.3M/720p @ (1–25/30 fps) Sub stream 1: D1/CIF/VGA@ (1–25/30 fps) Bit Rate Control CBR/VBR Video Bit Rate H.264: 512 kbps–8192 kbps H.265: 204 kbps–7936 kbps Day/Night Auto (ICR) BLC Yes WDR DWDR HLC Yes White Balance Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp Gain Control Auto; manual Noise Reduction 2D NR; 3D NR Motion Detection Yes Region of Interest (RoI) Yes Defog Electronic Image Rotation 180° S/N Ratio ? 55 dB Audio Audio Compression G.711a; G.711Mu Network Network Port RJ-45 (10/100 Base-T) 4G Yes Frequency Band LTE-FDD: B1/3/5/7/8/20/28 LTE-TDD: Band 38/40/41 WCDMA: Band 1/5/8 GSM: 850/900/1800 MHz Power Transmission CE: 4G: Power class3: 23 dBm ± 2.7 dB 3G: Power class3: 24 dBm + 1/-3 dB 2G: Power class0: 30 dBm ± 2 dB (GSM1800/1900) Power class5: 33 dBm ± 2 dB (GSM850/900) Network Protocol HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; 802.1x; SSL; Qos; FTP; UPnP; ICMP; SNMP; IGMP; ARP; RTCP; RTP; PPPoE; RTMP; Bonjour; SMB; NFS Interoperability ONVIF (Profile S&G&T);CGI;SDK;P2P Streaming Method Unicast/Multicast User/Host 20 (total bandwidth: 64 M) Storage FTP; Micro SD card (support up to 512 GB); NAS Browser IE 9 and later versions Chrome 41 and earlier versions Firefox 50 and earlier versions iOS 10 and later versions Management Software DMSS Mobile Client iOS; Android Certification Certifications CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; CE-RED: Radio Equipment Directive 2014/53/EU; FCC: 47 CFR FCC Part 15; Subpart B Port Audio Input 1 channel (built-in mic) Audio Output 1 channel (built-in speaker) Alarm Linkage Capture; record; send email; preset; audio; warning light Alarm Event Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; passive infrared detection Power Power Supply 5.4 VDC, 3A (Standard solar panel) Battery Life on a Full Charge Sleep Mode: 7days (at the rate of 1-hour remote live view per day) Power Consumption Sleep: 35 mW Static: 2.3 W (daytime,only SD storage) 2.5 W (daytime: pulling stream in 4G), 4.8 W (illuminator on, pulling stream in 4G) Max.: 10 W (illuminator + PTZ + heater + pulling stream in 4G) Environment Operating Temperature 0 °C to +50 °C (32 °F to +122 °F) Operating Humidity ? 95% Storage Temperature 0 °C to +50 °C (32 °F to +122 °F) Storage Humidity ? 95% Protection IP66 TVS 2000 V lightning proof; surge protection; voltage transient protection Structure Product Dimensions 336 mm × 247 mm × 223 mm (13.23" × 9.72" × 8.78") (L × W × H) Net Weight 1.40 kg (3.09 lb) Gross Weight 2.14 kg (4.72 lb)

Manufacturer Warranty
