Mechanical

• Dimensions Without mount: Ø86 x 112.6 mm (Ø3.4 x 4.4")

• With mount: Ø86 x 175.3 mm (Ø3.4 x 6.9")

• Weight Without mount: 675 g (1.5 lb)

• With mount: With mount: 820 g (1.8 lb)

• Enclosure materials Aluminum alloy, polycarbonate

• Mounting material Aluminum alloy

• Weatherproofing IP65

• Resistance IK04

Optics

• Sensor 1/1.8" 8MP sensor

• Lens F 4.1—12.3 mm; ƒ/1.53 -ƒ/3.3

• View angle Wide: 109.9° (H), 59.9° (V), 127.7° (D)

• Zoom: 34.9° (H), 19.7° (V), 40° (D)

• Night mode Built-in IR LED illumination and an IR cut filter

Video

• Video compression H.264

• Resolution 3840 x 2160 (16:9)

• Max. frame rate 30 FPS

• Image settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR

System

• Processor Quad-core Arm® Cortex®-A53 based chip

• Networking interface GbE RJ45 port

• Max. power consumption 11W

• Power method PoE

• Supported voltage range 37—57V DC

• LED R/G/B/W ring

• Button Factory reset

• Mounting Wall, ceiling, pole mount

• Operating temperature -20 to 50° C (-4 to 122° F)

• Operating humidity 0 to 90% noncondensing

• Certifications FCC, IC, CE

Audio

• Microphone Yes (Can be disabled)

• Speaker Yes

Software

• Web application UniFi Protect

• Mobile app UniFi Protect iOS™ and Android™
