Camera Image Sensor 1/2.7” CMOS Max. Resolution 2688 (H) × 1520(V) ROM 128 MB RAM 1 GB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.005 Lux@F2.0 (Color,30 IRE) 0.0005 Lux@F2.0 (B/W,30 IRE) S/N Ratio ?56 dB Lens Lens Type Fixed-focal Lens Mount M12 Focal Length 2.8 mm Max. Aperture 2.8 mm: F2.0 Field of View Horizontal: 101°; Vertical: 57°; Diagonal: 115° Iris Control Fixed Close Focus Distance 0.8 m DORI Distance Len Detect Observe Recognize Identify IPC- HUM8441- L4 61 m (200.1 ft) 24.4 m (80.1 ft) 12.2 m (40.0 ft) 6.1 m (20.0 ft) DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. Intelligence IVS (Perimeter Protection) Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection Smart Object Detection Smart abandoned object; smart missing object Face Detection Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attribute extraction including 6 attributes (gender, age, glasses, expressions, mask and beard) and 8 expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear); face snapshot set as face or one-inch photo; 3 snapshot strategies (real-time snapshot, optimization snapshot, and quality priority); face angle filter; optimization time setting Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) Smart Codec Smart H.265+ Smart H.264+ Video Frame Rate Main stream: 2688 × 1520 @25/30 fps Sub stream: 704 × 576 @25 fps; 704 × 480 @30 fps Third stream: 1920 × 1080 @25/30 fps Stream Capability 3 streams Resolution 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536);1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240); VGA (640 × 480) Bit Rate Control CBR/VBR Video Bit Rate H.264: 3 kbps–20480 kbps H.265: 3 kbps–20480 kbps Day/Night Color/B/W BLC Yes HLC Yes WDR 120 dB Scene Self-adaptation (SSA) Yes White Balance Auto; natural; street lamp; outdoor; manual; regional custom Gain Control Manual; auto Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest (RoI) Yes (4 areas) Defog Yes Image Rotation 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower) Mirror Yes Privacy Masking 4 areas Audio Audio Compression G.711a; G.711Mu; PCM; G.726; G.723 Alarm Alarm Event No SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, motion detection, video tampering, tripwire, intrusion, fast moving, missing object, abandoned object, parking detection, loitering detection, people gathering; scene changing, audio detection, voltage detection, external alarm, face detection , and security exception Network Network Port RJ-45 (10/100 Base-T) SDK and API Yes Network Protocol IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec User/Host 20 (Total bandwidth: 64 M) Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS Browser IE: IE8, IE9, and IE11 Chrome Firefox Management Software Smart PSS; DSS; DMSS Mobile Client IOS; Android Cyber Security Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade Certification Certifications CE-LVD:EN62368-1; CE-EMC:Electromagnetic Compatibility Directive 2014/30/EU; FCC:47 CFR FCC Part 15, Subpart B Port Audio Input 1 channel (3.5 mm JACK port) Audio Output 1 channel (3.5 mm JACK port) Alarm Input 2 channels in: 5 mA 3V–5V DC Alarm Output 2 channels out: 1,000 mA 30V DC/500mA 50V DC Power Power Supply 12V DC/PoE (802.3af) Dual Power Backup When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart. Power Consumption Basic: 2.4W (12V DC); 3W (PoE) Max. (Intelligence + WDR): 3.9W (12V DC); 4.8W (PoE) Environment Operating Temperature –40°C to +60°C (–40°F to 140°F) Operating Humidity ?95% Storage Temperature –40°C to +60°C (–40°F to 140°F) Structure Casing Metal Product Dimensions E1: 110 mm × 83 mm × 24 mm (4.33" × 3.27" × 0.94") L4: 35 mm × 35 mm × 26.7 mm (1.38" × 1.38" × 1.05") Net Weight 210 g (0.5 lb) Gross Weight 376 g (0.8 lb)
