Camera Image Sensor 1/3" CMOS Max. Resolution 2688 (H) × 1520 (V) ROM 128MB RAM 256MB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.01 Lux@F1.6 (Color,30IRE) 0.001 Lux@F1.6 (B/W,30IRE) 0 lux (Illuminator on) S/N Ratio >56 dB Illumination Distance IR: 50 m (164.04 ft) Warm light: 30 m (98.43 ft) Illuminator On/Off Control Auto;Manual Illuminator Number 1 (IR LED); 1 (Warm light) Angle Adjustment Pan: 0°–360° Tilt: –60°–0° Rotation: 0°–360° Built-in Battery Support 10000 mAh rechargeable lithium battery PIR Sensor Distance 10 m (the height of device is 2.5 m, placed horizontally) 5 m (the height of the device is 2 m, placed at an angle of 30° from the horizontal) Battery Battery Type Lithium-ion Capacity 10 Ah Max. Charging Voltage 4.2 V Operating Temperature 0 °C to +45 °C (32 °F to +113 °F) Battery Voltage 3.0 V to 4.2 V Cycle Lifetime Sleep Mode(Recommend): About 10 days (at the rate of 1-hour remote live view per day) General Mode: About 15 hours(when the battery is fully charged) Battery Life More than 500 cycles Battery Weight Approx. 190 g (0.42 lb) Solar Module Maximum Power 5 W Cell type Monocrystalline Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F) Dimensions 230 mm × 150 mm × 2 mm (9.1" × 5.9" × 0.1") (L × W × H) Standard testing condition AM = 1.5, 25 °C (77 °F), 1000 W/m², SMQ + 12% Lens Lens Type Fixed-focal Lens Mount M12 Focal Length 2.8 mm; 3.6 mm; 6 mm Max. Aperture 2.8 mm: F1.6 3.6 mm: F1.6 6 mm: F1.6 Field of View 2.8 mm: H: 102°; V: 54°; D:121° 3.6 mm: H: 84°; V: 42°; D:101° 6 mm: H: 52°; V: 48°; D:61° Iris Control Fixed Close Focus Distance 2.8 mm: 0.9 m (2.95 ft) 3.6 mm: 1.7 m (5.58 ft) 6 mm: 3.2 m (10.50 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8 mm 63.6 m (208.66 ft) 25.4 m (83.33 ft) 12.7 m (41.67 ft) 6.4 m (21.00 ft) 3.6 mm 85.4 m (280.18 ft) 34.2 m (112.20 ft) 17.1 m (56.10 ft) 8.5 m (27.89 ft) 6 mm 124.0 m (406.82 ft) 49.6m (162.73 ft) 24.8m (81.36 ft) 12.4m (40.68 ft) DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) Video Frame Rate Main stream: 2688 × 1520 @(1–25/30 fps ) sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps) Stream Capability 2 streams Resolution 4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 ×960 ); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–8192 kbps H.265: 32 kbps–8192 kbps Day/Night Auto(ICR)/Color/B/W BLC Yes HLC Yes WDR 120 dB Scene Self-adaptation (SSA) Yes White Balance Auto; natural; street lamp; outdoor; manual; regional custom Gain Control Auto Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest (RoI) Yes (4 areas) Smart Illumination Yes Mirror Yes Privacy Masking 4 areas Audio Built-in MIC Yes Built-in Speaker Yes Audio Compression G.711a;G.711Mu; G.726; PCM Alarm Alarm Event SD card error; SD card full; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception; PIR alarm; low battery alarm; light alarm; sound alarm Network Network Port RJ-45 (10/100 Base-T) Frequency 4G: FDD-LTE: B1/3/5/7/8/20/28 TDD-LTE: B38/40/41 Applicable regions: Europe, Asia-Pacific, Africa 3G: WCDMA: B1/5/8 Applicable regions: Europe, Asia-Pacific, Africa 2G: GSM/GPRS/EDGE: B3/5/8 Applicable regions: Europe, Asia-Pacific, Africa SDK and API Yes Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade Network Protocol IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P Interoperability ONVIF (Profile S/Profile G); CGI User/Host 20 (Total bandwidth: 80 M) Storage Bulit in eMMC (8 GB); FTP;SFTP; Micro SD card (support max. 256 GB); NAS Browser IE: IE8,9,11 Chrome Firefox Management Software DSS; DMSS Mobile Client iOS; Android Certification Certifications CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; CE-RED: Radio Equipment Directive 2014/53/EU; FCC: 47 CFR FCC Part 15; Subpart B Port USB 1 Micro USB Port Power Power Supply MicroUSB/5 VDC Power Consumption Sleep Mode: 0.03 W General Mode: 2.6 W Max. (4G pulling stream+IR+speaker+warning light): 4.9 W Power Adapter 5 VDC, 2 A Charging Cable Insulation Resistance?20M?;Conductor Resistance?3? Environment Operating Temperature 0 °C to +45 °C (32 °F to +113 °F) Operating Humidity ? 95% Storage Temperature 0 °C to +45 °C (32 °F to +113 °F) Protection IP67 Structure Casing Metal + plastic Product Dimensions 247 mm × 219 mm×179 mm (9.72" × 8.62" × 7.05") (L × W × H) Packaging Dimensions 238 mm×181 mm×296 mm (9.37"×7.13"×11.65") (L × W × H) Net Weight 1250 g (2.80 lb) Gross Weight 1610 g (3.50 lb)
