GR-GSC3516

The GSC3516 is a SIP/Multicast Talk-Back Speaker that allows offices, schools, hospitals, apartments and more to build powerful voice intercom solutions that expand security and communication. This robust SIP intercom device offers 2-way voice functionality with both a high-fidelity 15W HD speaker and 3 directional microphones with Multichannel Microphone Array Design (MMAD) an d 1 omnidirectional auxiliary microphone that offer a 4.2 meter pickup distance. The GSC3516 supports a wide-range of peripherals including Bluetooth devices, built-in whitelists, blacklists and greylists to easily block unwanted calls, integrated dual-band Wi-Fi and advanced acoustic echo cancellation. By pairing the GSC3516 with other Grandstream devices, including desktop and cordless IP phones a s well as the GDS series of Facility Access products, users can easily sculpt a state-of-the-art security a nd voice intercom solution. Thanks to it’s modern industrial design, cleanable exterior surface and rich features, the GSC3516 is the ideal intercom speaker/microphone for any setting.

Features:

Full-duplex speakerphone with HD acoustic chamber, advanced acoustic echo cancellation
3 directional mics with MMAD & microphone beamforming array and 1 omnidirectional
auxiliary microphone
Full-band and wide-band audio codec support including Opus & G.722
Integrated dual-band 802.11 a/b/g/n/ac Wi-Fi and Bluetooth
One 10/100Mbps network port with PoE/PoE+
2-pin multi-purpose input to support peripherals including call buttons

(GSC3516)

Protocols/Standards SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR,HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, LLDP-MED, SIMPLE, LDAP,TR-069, 802.1x, TLS, SRTP, IPv6, OpenVPN® Network Interfaces One 10/100 Mbps port with integrated PoE/PoE+ Operating System Linux Bluetooth Yes, integrated. Bluetooth 2.1+Enhanced Data Rate (EDR)+ BT4.2 Wi-Fi Yes, dual-band 2.4 & 5GHz with 802.11 a/b/g/n/ac Auxiliary Port One 2-pin multi-purpose input port, Reset Voice Codecs and Capabilities G.711µ/a, G.722 (wide-band), G.726-32, iLBC, Opus, G.723, G.729A/B, in-band and out-ofband DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC, ANS Telephony Features SIP Paging, Multicast Paging, Group Paging, PTT, Call-waiting with priority override, Bluetooth SCO call HD Audio Yes, HD speakerphone with support for full band audio with 48KHz voice sampling frequency Speaker 15W high-fidelity HD speaker Frequency: 110Hz-20000 Hz Sensitivity: Up to 90 dBA at 1W power at 0.5 meter Microphone 3 directional microphones with beam-forming capability and 1 omnidirectional auxiliary microphone that offer a 4.2 meter pickup distance QoS Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS Security User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access control,secure boot Multi-language English, German, French, Spanish, Portuguese, Russian & Chinese Upgrade/Provisioning Firmware upgrade via TFTP / HTTP / HTTPS or local HTTP upload, mass provisioning using GDMS/TR069 or AES encrypted XML configuration file Power & Green Energy Efficiency Integrated PoE* 802.3af Class 3, PoE+ 802.3at Class 4 Temperature and Humidity Operation: 0°C to 45°C Storage: -10°C to 60°C, Humidity: 10% to 90% Non-condensing Package Content GSC3516 SIP/Multicast Talk-Back Speaker, mounting kits, quick installation guide Physical Unit Dimensions: 257mm (diameter) x 68.5mm (depth) Unit Weight: 0.92kg , Box Weight: 1.75kg Compliance FCC: FCC 47 CFR Part 15 Subpart B;FCC 47 CFR Part 15 Subpart C;FCC 47 CFR Part 15 Subpart E. IC: ICES-003;RSS-247 Issue 2;RSS-Gen Issue 5;RSS-102 Issue 5. CE: ETSI EN 300 328;ETSI EN 301 893;ETSI EN 300 440;ETSI EN 301 489-1;ETSI EN 301 489-3;ETSI EN 301 489-17;EN 55032;EN 55035;EN IEC 61000-3-2;EN 61000-3- 3;EN IEC 62311;EN IEC 62368-1. UKCA: ETSI EN 300 328;ETSI EN 301 893;ETSI EN 300 440;ETSI EN 301 489-1;ETSI EN 301 489-3;ETSI EN 301 489-17;BS EN 55032;BS EN 55035;BS EN IEC 61000-3- 2;BS EN 61000-3-3;BS EN IEC 62311;BS EN IEC 62368-1. RCM: AS/NZS CISPR 32;AS/NZS 62368.1;AS/NZS 4268;AS/NZS 2772.2.

SKU	GSC3516
Barcode #	6947273704287
Brand	GRANDSTREAM
Shipping Weight	2.0000kg
Shipping Width	0.170m
Shipping Height	0.330m
Shipping Length	0.060m
Shipping Cubic	0.003366000m3
