Small Form Factor Business Desktop

Lenovo ThinkCentre M70s Gen 5 12U3002JAU

The Lenovo ThinkCentre M70s Gen 5 is a compact desktop computer with a 14th Gen Intel Core i7-14700 processor, 16GB DDR5 memory, a 512GB PCIe 4.0 NVMe SSD, Intel UHD Graphics 770, Wi-Fi 6, Bluetooth, Windows 11 Pro and three-year onsite support.

What is the Lenovo ThinkCentre M70s Gen 5 12U3002JAU?

It is a small form factor ThinkCentre desktop designed to combine strong multitasking performance, fast solid-state storage, integrated graphics and wired and wireless connectivity in a space-efficient chassis.

Core i7-14700 14th Gen Intel processor with 20 cores and 28 threads

16GB DDR5 2 x 8GB memory configuration running at 5600MHz

512GB NVMe M.2 PCI Express NVMe 4.0 x4 solid-state storage

Wi-Fi 6 Wireless LAN, Bluetooth and Gigabit Ethernet connectivity

Premium Performance and Solid Reliability

A compact ThinkCentre desktop for productive day-to-day business computing.

Whether used by a small business or within a large IT department, the ThinkCentre M70s Gen 5 is presented as a reliable, easy-to-use and productive desktop platform. Its small form factor design helps simplify placement while retaining access to internal components for supported hardware upgrades.

Processor, Memory and Storage

Core hardware designed for responsive multitasking and everyday application performance.

14th Gen Intel Core i7

The Intel Core i7-14700 processor runs at 2.10GHz and reaches up to 5.40GHz, with 20 cores and 28 threads for demanding multitasking workloads.

16GB DDR5 Memory

A 2 x 8GB DDR5 memory configuration supports simultaneous applications and heavy multitasking. The supplied specifications list support for up to 64GB.

512GB PCIe NVMe SSD

The M.2 PCI Express NVMe 4.0 x4 solid-state drive provides fast data access and 512GB of storage capacity.

Graphics, Connectivity and Ports

Integrated display output, network access and peripheral connectivity.

Intel UHD Graphics 770

Integrated Intel UHD Graphics 770 uses shared DDR5 system memory for HD video playback, photo editing and office applications.

Wi-Fi 6, Bluetooth and Ethernet

Wireless LAN using IEEE 802.11ax, Bluetooth and Gigabit Ethernet provide flexible wired and wireless network connectivity.

Nine USB Ports

The supplied specifications list nine USB ports, including front USB-C with 5Gbps data and 15W charging, four USB 3.2 Gen 1 ports and four rear USB 2.0 ports.

Windows 11 Pro and Included Accessories

Ready for business use with an English-language operating system and input devices.

The ThinkCentre M70s Gen 5 includes Windows 11 Pro in English. The package contents list the desktop computer, an English-localised keyboard and a mouse. The supplied warranty information specifies three-year onsite support.

Frequently Asked Questions

Quick answers based on the supplied product information.

Which processor is installed?

This configuration includes a 14th Gen Intel Core i7-14700 processor with 20 cores, 28 threads and a maximum turbo speed of 5.40GHz.

How much memory does it include?

It includes 16GB of DDR5 memory configured as 2 x 8GB. The supplied specifications list a maximum supported capacity of 64GB.

What storage is installed?

It includes a 512GB M.2 PCI Express NVMe 4.0 x4 solid-state drive.

Does it include Wi-Fi and Bluetooth?

Yes. The supplied specifications list Wi-Fi 6 wireless LAN and Bluetooth.

Which operating system is included?

Windows 11 Pro in English is included.

What display outputs are listed?

The rear connections include HDMI and one DisplayPort output.

What warranty support is supplied?

The supplied product information lists three-year onsite support.

(12U3002JAU)

Lenovo ThinkCentre M70s Gen 5 12U3002JAU Specifications

Review the processor, memory, storage, graphics, connectivity, ports, operating system, physical and support details.

Specification	Details
General Information
Brand	Lenovo
Product Name	ThinkCentre M70s Gen 5 12U3002JAU
Product Line	ThinkCentre
Product Series	M70s Gen 5
Product Model	12U3002JAU
Manufacturer Part Number	12U3002JAU
Product Type	Desktop Computer
Release Year	2025
Processor and Chipset
Processor Manufacturer	Intel
Processor Type	Core i7
Processor Model	i7-14700
Processor Generation	14th Gen
Processor Speed	2.10GHz
Maximum Turbo Speed	5.40GHz
Processor Cores	Icosa-core (20 Core)
Processor Threads	28
Chipset Manufacturer	Intel
Chipset Model	Q670
Systems Management	No vPro Support
Memory
Standard Memory	16GB
Memory Configuration	2 x 8GB
Memory Technology	DDR5 SDRAM
Memory Speed	5600MHz
Maximum Memory Supported	64GB
Occupied Memory Slots	2
Free Memory Slots	0
Storage
Drive Type	SSD
Total SSD Capacity	512GB
SSD Form Factor	M.2
SSD Interface	PCI Express NVMe 4.0 x4
Display and Graphics
Graphics Controller Manufacturer	Intel
Graphics Controller Model	UHD Graphics 770
Graphics Memory Technology	DDR5 SDRAM
Graphics Memory Accessibility	Shared
Network and Communication
Wireless LAN	Yes
Wireless LAN Standard	IEEE 802.11ax
Wi-Fi Generation	Wi-Fi 6
Bluetooth	Yes
Ethernet Technology	Gigabit Ethernet
Ethernet Ports	1
Interfaces and Ports
Total USB Ports	9
Front USB-C	1 x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with 15W charging
USB 3.2 Gen 1 Ports	4
Rear USB 2.0 Ports	4
Rear HDMI	Yes
Rear DisplayPort	Yes
Rear DisplayPort Outputs	1
Operating System
Operating System	Windows 11 Pro
Operating System Platform	Windows
Operating System Language	English
Input Devices and Package Contents
Keyboard Localisation	English
Package Contents	ThinkCentre M70s Gen 5 12U3002JAU Keyboard Mouse
Physical Characteristics
Form Factor	Small Form Factor
Product Colour	Black
Colour Family	Black
Height	339.5mm
Width	92.5mm
Depth	297.7mm
Weight	Approximately 5.30kg
Shipping Weight	6.3kg
Power
Maximum Power Supply Wattage	260W
Security and Environmental Information
Features	Security Slot
Environmentally Friendly	Yes
Environmental Certifications	Electronic Product Environmental Assessment Tool Gold (EPEAT Gold) TCO Certified 9.0 GREENGUARD
Energy Star	Yes
TCO Certified	Yes
Energy Efficiency Certification	ENERGY STAR 8.0
Energy Efficiency Compliance	Energy-related Products Directive Lot 3 (ErP Lot 3)
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Warranty
Additional Warranty Information	3 Year Onsite

SKU	12U3002JAU
Brand	LENOVO
Shipping Weight	6.3000kg
Shipping Width	0.540m
Shipping Height	0.190m
Shipping Length	0.390m
Shipping Cubic	0.040014000m3
