Smart Video Intercom Kit with Wi-Fi & PoE Support

7" Touch Screen Monitor | IP66 Outdoor Station | Mobile App Management

Secure your premises with this professional-grade Video Intercom Kit, featuring a high-resolution 7-inch capacitive touch screen and a rugged IP66-rated outdoor station. This system integrates seamlessly into your smart home or office, offering Wi-Fi connectivity and mobile app support to receive calls and unlock doors from anywhere. With support for IP cameras (IPCs), group calling, and alarm integration, it provides a comprehensive surveillance and access control solution that is both easy to install via Standard PoE and powerful enough for advanced security needs.

VTH Indoor Monitor Features

Responsive Touch Interface: 7" TFT capacitive screen (1024 × 600) for crystal-clear video and intuitive navigation.
Universal Connectivity: Connects to both analog and digital outdoor stations (VTOs) and indoor monitors (VTHs), plus IP camera integration.
Smart Notifications: Supports app management to receive real-time calls, alarm messages, and remote door opening via your smartphone.
Security Logging: Capture snapshots and record videos of visitors directly to an SD card (required) for later review.

VTO Outdoor Station Specs

Weatherproof Durability: IP66 rated to withstand harsh outdoor conditions, dust, and heavy rain.
Clear Imaging: Digital Wide Dynamic Range (DWDR) ensures clear video even in challenging lighting or backlit conditions.
Tactile Operation: Features a reliable mechanical button and adjustable volume for clear two-way voice communication.
Alarm Integration: 6-channel alarm input and 1-channel alarm output for enhanced perimeter security.

Complete Access Control and Monitoring Solution

This Video Intercom Kit is the ideal choice for modern residential and commercial security. By utilizing Standard PoE (Power over Ethernet), the system simplifies wiring by providing both power and data over a single cable. The indoor monitor serves as a centralized hub, allowing for group calls and the monitoring of additional IP cameras throughout the property. With its H.264 video decoding and sleek surface-mount design, this kit offers a professional, reliable way to manage visitors, enhance security through alarm integration, and enjoy the convenience of remote mobile access.

(DH-KTH01M)

Detailed Specifications: Dahua Video Intercom System

Indoor Monitor: DHI-VTH2624GW-WP

Display

7" TFT Capacitive Touchscreen (1024 × 600)

Hybrid Support

Full Digital and Analog (4-wire) Communication

Wireless

Wi-Fi (IEEE802.11b/g/n) 2.4 GHz

I/O Interface

6x Alarm Input, 1x Alarm Output, 1x RS-485, 4x 4-wire ports

Audio
