DHI-VTO2201F-P System Main Processor Embedded processor Operating System Embedded Linux Operation System Button Type Mechanical Interoperability ONVIF; CGI Network Protocol RTSP;RTMP;HTTP/HTTPS;DNS; UPnP;RTP;SIP;SSH; ONVIF ;P2P Basic Camera 1/2.9" 2MP CMOS Low Illumination HD Colorful Camera Field of View Horizontal: 140°; vertical: 79.6; diagonal:159° Focal Length 2.0 mm WDR 120 dB Noise Reduction 3D DNR Video Compression H.265 Video Resolution 50Hz: Main Stream (720P@25 fps), sub stream (1080P@25 fps) 60Hz: Main Stream (720P@30 fps), sub stream (1080P@30 fps) Video Frame Rate 25 fps Video Bit Rate 256 Kbps to 8 Mbps Light Compensation Auto IR Day/Night Auto (ICR) Audio Compression G.711a; G.711u; PCM Audio Input 1 channel Audio Output Built-in speaker Audio Mode 2-way voice communication Audio Enhancement Echo suppression/digital noise reduction Audio Bit Rate 16 KHz, 16 Bit Status Indicator Light 3 Port RS485 1 Alarm Output 1 Power Output 1-ch 12 VDC 100mA Exit Button 1 Door Status Detection 1 Lock Control 1 Network Port One RJ45 10M/100M network port General Appearance color Silver Power Supply DC 24V 1A Standard PoE Power Adapter Optional Installation Flush/surface mount Certifications CE; FCC; UL Product Dimensions 130 mm × 96 mm × 28.5 mm (5.12" × 3.78" × 1.12") Protection IK07; IP65 Operating Temperature –30°C to +60°C (–22°F to 140°F) Operating Humidity 10%–90% (RH, non-condensing) Operating Altitude 0 m–3000 m Power Consumption ? 8W Net Weight 0.35 kg (0.77 lb) Gross Weight 0.4 kg (0.88 lb) DHI-VTH2621GW-P System Main Processor Embedded processor Operating System Embedded Linux Operation System Network Protocol RTSP; RTP; SIP; DNS; SSH ROM 128 MB RAM 128 MB CPU Dual core 1.2 GHz Basic Screen Type Capacitive touchscreen Display Screen 7-inch TFT Resolution 1024 × 600 Audio Compression G.711a; G.711u; PCM Audio Input 1 Audio Output Built-in speaker Audio Mode 2-way voice communication Audio Enhancement Echo suppression Audio Bit Rate 16 KHz, 16 Bit Function Communication Mode Full digital Information Release Receive and view text information released by the management center DND Mode Do not disturb period can be set; Do not disturb mode Number of Extensions Villa: 9 Apartment: 4 Performance Casing PC + ABS Port Alarm Input 6 Alarm Output 1 Power Output 1 (12 V/200 mA) Door Bell Yes (use any alarm input port) Network One 10/100 Mbps Ethernet Alarm SOS Yes General Appearance color White Power Supply 12 VDC 1A; Standard PoE (36–57 V, 0.35 A) Power Adapter Optional Installation Surface mount Certifications CE; FCC Accessory Bracket and alarm ribbon cable (included) Product Dimensions 189.0 mm × 130.0 mm × 26.9 mm (7.44" × 5.12" × 1.06") Operating Temperature –10°C to +55°C (14°F to 131°F) Operating Humidity 10%–95% (RH, non-condensing) Operating Altitude Beneath 3,000 m (9,842.52 ft) Power Consumption Standby ? 2W, working ? 6W Net Weight 0.34 kg (0.74 lb) Gross Weight 0.58 kg (1.27 lb) DH-PFS3005-4ET-36E General Network Port Port1-4: 4 × RJ-45 10/100 M (PoE) Port 5: 1 × RJ-45 10/100 M (uplink) Appearance color Black Power Supply 100–240 VAC Power Adapter Standard Certifications CE; FCC; UL Product Dimensions 170 mm × 100 mm × 35 mm (6.69" × 3.94" × 1.38") Operating Temperature –10 °C to +55 °C (+14 °F to +131 °F) Operating Humidity 10%–95% (RH), non-condensing Operating Altitude 0–3000 m (0–9842.52 ft) Net Weight 0.45 kg (0.99 lb)

Manufacturer Warranty
