System Main Processor Embedded Processor Operating System Embedded Linux OS Button Type Mechanical Number of Buttons 12 Basic Camera 1/2.9" 2 MP CMOS Field of View H:140°,V:80°, D:160° WDR 120 dB Noise Reduction 3D NR Video Compression H264?H265 Video Resolution Main stream: 720p,WVGA, D1, CIF Sub stream: 1080p,WVGA, D1, QVGA, CIF Video Frame Rate 25 fps Light Compensation Auto white light Day/Night Color/B/W Audio Compression G.711a, G.711u, PCM Audio Input 1 Audio Output Built-in Speaker Audio Mode Two-way audio Audio Enhancement Echo suppression/digital noise reduction Audio Bit Rate 16 KHz, 16 bit Function Communication Mode Digital 2-wire Unlock Mode Card swiping;password;remote Card Type Mifare card Auto Snapshot Yes (SD card inserted in VTH or FTP server is configured for VTO) Leave Videos Yes (SD card is inserted in the indoor monitor or door station) Storage Supports Micro SD card (up to 256 GB) Web Configuration Yes RFID Modulation Type AM Frequency Range 13.56 MHz Max. Transmission Power 42dBuA/m @10m Performance Card Reading Distance 0 cm–3 cm (0"–1.18") Casing Material Aluminum Capacity Card Capacity 10000 Port RS-485 1 Wiegand 1 Alarm Input 1 Alarm Output 1 Power Output 1 port,12 V/600 mA Door Bell 1 Exit Button 1 Lock Control 1 Network Port 1 × RJ-45 port?10Mbps/100Mbps network port Alarm Tamper Alarm Yes General Appearance Color Silver Power Supply 48 VDC, 0.4 A, PoE (802.3af/at) Power Adapter Optional Installation Flush Mount;Surface Mount Certifications CE Accessory Flush mount box (optional); Surface mount box (optional) Product Dimensions 200.0 mm × 98.0 mm × 35.4 mm (7.87" × 3.86" × 1.39") Protection IK08, IP65 (silicone sealant is needed, see the quick start guide) Operating Temperature –40 °C to +60 °C (–40 °F to +140°F) Operating Humidity 10%–90% (RH), non-condensing Operating Environment Outdoor Operating Altitude Beneath 3000 m (9842.52 ft) Power Consumption ? 5 W (standby), ? 7 W (working) Gross Weight 692 g (1.53 lb) Storage Temperature 0 °C to +40 °C (+32 °F to +104 °F) Storage Humidity 30%–75%(RH)
