System Parameter Operating System Embedded LINUX operating system Network Protocol IPv4, FTP, RTSP, RTP, TCP, UDP, SIP Keyboard Type Touch keyboard (0–9, *, #) Basic Parameter Screen Type Capactive screen Display 10-inch TFT LCD Resolution 1024 (H) × 600 (V) Video Compression H.264 Audio Compression G.711a, G.711Mu, G.711u, PCM Audio Input 1 channel all-direction microphone Audio Output 1 channel Audio Mode Support dual-way bidirectional talk Audio Enhancement Support echo suppression/DNR Function Parameter Communication Mode Full digital Leave Videos or Text Messages Support DND Mode Support Sub-station Quantity 9 Edge Storage Embedded 8 GB Port Alarm Input 6 channels Alarm Output 1 channel Doorbell Supported by every channel Network 1 RJ-45, 10 M/100 Mbps self-adaptive Alarm Parameter SOS Alarm Support General Parameter Casing PC+ABS Appearance Color Black Power Supply Standard PoE DC 12V 1A Power Optional Installation Surface Certifications CE/FCC Dimensions 260 mm × 170 mm × 28 mm (10.24" × 6.69" × 1.10") Operating Temperature -10°C to +55°C (+14°F to +131°F ) Operating Humidity 10%RH–90%RH (No condensation) Power Consumption ?7W (Work)
