Video Intercom KIT VTH > 7" TFT capacitive touch screen, 1024 × 600. > Wi-Fi. > H.264 video decoding.Connects to analog and digital VTOs, and analog and digital VTHs. > Connects to IPCs. > Features group call.Supports recording videos and capturing snapshots (SD card is required). > 6-channel alarm input and 1-channel alarm output. > Supports app management, receiving calls and alarm messages, and monitoring and opening the door > Standard PoE. > Surface mount. VTO > Unlock, voice call, video call and volume adjustment. > Multiple bell sounds. > Supports digital wide dynamic range (DWDR). > Mechanical button. > IP66.

(DH-KTH01)

DHI-VTH2624GW-WP System Main Processor Embedded Processor Operating System Embedded operating system Network Protocol UDP; TCP; FTP; IPv4; DNS; RTSP; SSH; SIP; P2P; RTP Interoperability ONVIF Basic Screen Type Capacitive Touchscreen Display Screen 7" TFT Screen Resolution 1024 (H) × 600 (V) Audio Compression G.711a; G.711u; PCM Audio Input 1 channel Audio Output Built-in speaker Audio Mode Two-way audio with VTO (halfduplex); Two-way audio with app (fullduplex) Audio Enhancement Echo suppression/digital noise reduction Audio Bit Rate 16 KHz; 16 Bit Function Communication Mode Full digital; Analog Information Release Receive and view text information released by the management center Leave Videos Yes (SD card needed) DND Mode Do not disturb period can be set; Do not disturb mode can be set Number of Extensions Villa: 9 digital extensions and 2 analog extensions Apartment: 4 digital extensions and 2 analog extensions Wi-Fi Yes Wireless Standard IEEE802.11b; 802.11g; 802.11n Wireless Frequency Range 2.4 GHz Storage Micro SD card (up to 64 GB) Port RS-485 1 Alarm Input 6 Alarm Output 1 Power Output 1 (12 V, 200 mA) Door Bell Yes (use the alarm input port) Network Port 1 × RJ-45 10/100 Mbps Ethernet port 4-wire 4 Performance Casing Material PC and ABS General Appearance Color White Power Supply 12 VDC, 1 A Standard PoE Power Adapter Optional Installation Surface Mount Certifications CE Accessory Included: Power cord 485 and Power output ribbon cable alarm ribbon cable bracket Product Dimensions 189.57 mm × 134.57 mm × 26 mm (7.46" × 5.30" × 1.02") Operating Temperature 10 °C to +55 °C (+14 °F to +131 °F) Operating Humidity 10%90% (RH) Operating Altitude 0 m3000 m (0 ft9842.52 ft) Power Consumption ?3.8 W (standby), ?8.9 W (working) Gross Weight 604 g (1.33 lb) Storage Temperature 0 °C to 40 °C (+32 °F to +104 °F) Storage Humidity 30%75% Anti-corrosion Level Basic Protection Operating Environment Indoor DHI-VTO1000JM System Button Type Mechanical Basic Camera 1.3MP CMOS Field of View Horizontal: 70° Vertical: 40° WDR DWDR Illuminator Type Auto IR Day/Night ICR auto switch Audio Input 1 channel to the microphone; pickup distance 0.5 m Audio Output 1 channel to the speaker Status Indicator 1 indicator light Green: Power on Function Communication Mode Analog Unlock Mode Local unlock Performance Casing ADC12 Port Exit Button 1 Door Status Detection 1 General Color Black Power Supply Powered by indoor monitor Installation Surface mount Certifications CE/FCC Accessory Rain cover (included) Dimensions 131.45 mm × 46.00 mm × 33.80 mm (5.18" × 1.81" × 1.33") Protection Grade IP66 (Apply silicon sealant to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.) Operating Temperature -30°C to +60°C (-22°F to +140°F) Operating Humidity 10%RH95%RH Power Consumption ? 1W (standby) ? 3W (working) Net Weight 0.18 kg (0.40 lb) Gross Weight 0.38 kg (0.84 lb)
