System Operation system Embedded Linux operation system Interoperability Support Onvif Internet Protocol IPv4, DNS, RTSP, RTP, TCP, UDP, SIP Basic Screen Type Capacitive Screen Display 7 inch TFT display Resolution 1024(H)×600(V) Video Encoding H.264 Audio Encoding PCM Audio Input 1 channel Audio Output 1 built-in speaker and 1 handset speaker Audio Mode Full duplex communication Audio Enhancement Echo suppression and cancellation/digital noise reduction Audio Bit Rate 16KHz, 16Bit Status Indicator Light 1 red indicator light flickers constantly during upgrade Function Storage SD card is supported and the maximum capacity is 32GB Communication Methods Full digital Information Release Text messages can be received and viewed on the indoor monitor (images can be received if SD card is inserted) Elevator Control You can control the elevator through the indoor monitor Leave Photos and Messages Yes (SD card is needed) Do Not Disturb Mode Yes Extension Quantity Villa: 9 extensions apartment: 4 extensions Wi-Fi Yes Wireless Standard IEEE802.11b/802.11g/802.11n Wireless Frequency Range 2.4GHz Wireless Security Encryption 64/128bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS Port RS-485 1 Alarm Input 6 (digital quantity) Alarm Output 1 (digital quantity) Power Output 1 12V/100mA power output port Door bell Yes (Use alarm input port) Network 1 RJ-45 100Mbps port Alarm SOS Yes Performance Housing Material PC+ABS Regular Power Supply Mode 12V DC 1A, standard PoE Installation Method Surface mount (this equipment is only suitable for mounting at heights ? 2m) Certification CE, FCC Accessory Bracket Alarm cable RS-485 cable Product Dimensions 236.0mm×129.8mm×23.0mm (9.29"×5.11"×0.91") Working Temperature -10°C to +55°C (+14°F to +131°F) Working Humidity 10%RH–90%RH (non-condensing) Working Altitude Less than 3,000 meters Power Consumption ?2W (standby), ?5W (working) Net Weight 566g (1.25 lb) Gross Weight 917g (2.02 lb)
