Technical Speci?cation Model DHI-VTO3222E-P System(VTO) Main Processor Embedded Processor Operating System Embedded Linux OS Button Type Mechanical Interoperability ONVIF Network Protocol SIP; P2P; IPv4; DNS; RTSP; RTP; TCP; UDP Basic(VTO) Camera 1/2.9" 2 MP CMOS Field of View H: 140°, V: 80°, D: 160° WDR 120 dB Noise Reduction 3D NR Video Compression H264, H265 Video Resolution Main stream: 720p, WVGA, D1, CIF Sub stream: 1080p, WVGA, D1, QVGA, CIF Video Frame Rate 25 fps Light Compensation Auto white light Day/Night Color/B/W Audio Compression G.711a, G.711u, PCM Audio Input 1 Audio Output Built-in speaker Audio Mode Two-way audio Audio Enhancement Echo suppression, digital noise reduction Audio Bit Rate 16 KHz, 16 bit Function(VTO) Communication Mode 2-wire Unlock Mode Card; password; remote unlock Card Type Mifare card Auto Snapshot Yes (SD card is inserted in the indoor monitor or door station) Leave Videos Yes (SD card is inserted in the indoor monitor or door station) Storage Supports Micro SD card (up to 256 GB) Web Configuration Yes Performance(VTO) Card Reading Distance 0 cm–3 cm (0"–1.18") Casing Material Aluminum alloy Capacity(VTO) Card Capacity 10000 Port(VTO) RS-485 1 Wiegand 1 Alarm Input 1 Alarm Output 1 Power Output 1 (12 V, 600 mA) Door Bell 1 Exit Button 1 Lock Control 1, normally closed by default Network Port 1 × RJ-45, 10 Mbps/100 Mbps network port Alarm(VTO) Tamper Alarm Yes General(VTO) Appearance Color Silver Power Supply 48 VDC, 0.4 A; PoE (802.3af/at) Power Adapter Optional Installation Surface mount (The surface mount kit comes with the surface mount bracket) Certifications CE Product Dimensions 200.0 mm × 98.0 mm × 35.4 mm (7.87" × 3.86" × 1.39") Protection IK08, IP65 (Silicone sealant is needed, see the quick start guide) Operating Temperature –40 °C to +60 °C (–40 °F to +140°F) Operating Humidity 10%–95% (RH), non-condensing Operating Altitude Beneath 3000 m (9842.52 ft) Operating Environment Outdoor Power Consumption ?5 W (standby), ?7 W (working) Gross Weight 692 g (1.53 lb) Storage Humidity 30%–75% (RH) Storage Temperature 0 °C to +40 °C (+32 °F to +104 °F) Model DHI-VTH2621GW-WP System (VTH) Main Processor Embedded Processor Operating System Embedded Linux OS Network Protocol RTSP; DNS; RTP; SIP; SSH Basic (VTH) Screen Type Capacitive Touchscreen Display Screen 7" TFT Screen Resolution 1024 (H) × 600 (V) Audio Compression G.711a; G.711u; PCM Audio Input 1 Audio Output Built-in speaker Audio Mode Two-way audio Audio Enhancement Echo suppression Audio Bit Rate 16 KHz; 16 bit Function (VTH) Communication Mode Full digital Information Release Receive and view text information released by the management center Leave Videos Yes (SD card inserted in VTH is needed) DND Mode Do not disturb period can be set Number of Extensions Villa: 9 extensions; Apartment: 4 extensions Port (VTH) Alarm Input 6 Alarm Output 1 Door Bell Yes (reuse the alarm input port) Network Port 1 × RJ-45 10/100 Mbps Ethernet port Performance (VTH) Casing Material PC + ABS General (VTH) Appearance Color White Power Supply 12 VDC, 1 A; Standard PoE Power Adapter Optional Installation Surface Mount Certifications CE Accessory Bracket and alarm ribbon cable (included) Product Dimensions 189.6 mm × 134.6 mm × 26.0 mm (7.50" × 5.30" × 1.00") Operating Temperature –10 °C to +55 °C (+14 °F to +131 °F) Operating Humidity 10%–95% (RH), non-condensing Operating Altitude Beneath 3000 m (9842.52 ft) Operating Environment Indoor Power Consumption ?2 W (standby), ?6 W (working) Gross Weight 575 g (1.27 lb) Storage Temperature 0 °C to +40 °C (+32 °F to +104 °F) Storage Humidity 30%–75% (RH) Model DH-PFS3006-4ET-36 System (Networking Device) Main Processor Embedded Processor Port (Networking Device) Network Port 4 × PoE ports with 10/100 Mbps Base-TX 2 uplink ports with 10/100 Mbps Base-TX General (Networking Device) Power Supply Built-in power supply: 100–240 VAC Certifications CE; FCC Product Dimensions 194.0 mm × 108.1 mm × 35.0 mm (7.64" × 4.26" × 1.38") (L × W × H) Operating Temperature –10 °C to +55 °C (+14 °F to +131 °F) Operating Humidity 10%–90% (RH), non-condensing Power Consumption Idling: 0.5 W; Full load: 36 W Gross Weight 1.11 kg (2.15 lb)
