Camera Image Sensor 1/1.8” 4Megapixel progressive scan CMOS Effective Pixels 2688 (H) × 1520 (V) RAM/ROM 1 GB/128 MB Scanning System Progressive Electronic Shutter Speed Auto/Manual, 1/3 s–1/100000 s Minimum Illumination 0.003 Lux@F1.8 IR Distance Distance up to 40 m (131 ft) IR On/Off Control Auto/Manual IR LEDs 3 Lens Lens Type Motorized vari-focal Mount Type Board-in Focal Length 2.7 mm–12.0 mm Max. Aperture F1.8 Angle of View H: 114°–47°, V: 62°–26° Aperture Type Auto Close Focus Distance 1.2 m (3.94 ft) DORI Distance Lens Detect Observe Recognize Identify W 58m(190ft) 23m(75ft) 12m(39ft) 6m(20ft) T 131m(430ft) 52m(171ft) 26m(85ft) 13m(43ft) Pan/Tilt/Rotation Pan/Tilt/Rotation Range Pan: 0?–355?; Tilt: 0?–75?; Rotation: 0?–355? Artificial Intelligence Face Detection Support face image capture Face Attributes Support 6 kinds of face attributes extraction: Age, Gender, Expression(Jolly, Surprise, Normal, Rage, Sad, Disgusted, Confused, Frightened), Glasses,Mouth Mask, Moustache & Beard Perimeter Protection Tripwire, intrusion (Recognition of vehicle and people), fast moving, loitering detection, parking detection and people gathering People Counting Support Line crossing/Region/Queueing people counting; Support 4 accesses independent detection, 4 areas independent detection General Intelligence Event Trigger Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly General Intelligence Object Abandoned/Missing Heat Map Yes Video Compression H.265,H.264,H.264B,H.264H, MJPEG (sub stream) Smart Codec Yes Streaming Capability 3 Streams Resolution 2688 × 1520/2560 × 1440/2304 × 1296/1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) Frame Rate Main Stream: 2688 × 1520 (1 fps–25/30 fps) 2560 × 1440 (1 fps–25/30 fps) 1920 × 1080 (1 fps–50/60 fps) Sub Stream: D1 (1 fps–25/30 fps) D1 (1 fps–50/60 fps) Third Stream: 1080P (1 fps–16 fps) Bit Rate Control CBR/VBR Bit Rate H.264: 32 Kbps–8192 Kbps H.265: 19 Kbps–8192 Kbps Day/Night Auto(ICR)/Color/B/W BLC Mode BLC/HLC/WDR (140 dB) White Balance Auto/Natural/Street Lamp/Outdoor/Manual Gain Control Auto/Manual Noise Reduction 3D DNR Motion Detection Off/On (4 Zone, Rectangle) Region of Interest Off/On (4 Zone) Electronic Image Stabilization (EIS) Yes Smart IR Yes Defog Yes Flip 0°/90°/180°/270° Mirror Off/On Privacy Masking Off/On (4 Area, Rectangle) Audio Compression G.711a, G.711Mu, G.726, AAC, G.723 Network Ethernet RJ-45 (10/100 Base-T) Protocol IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP Interoperability ONVIF (Profile S/Profile G/Profile T), CGI, Milstone, Genetec, P2P Streaming Method Unicast/Multicast Max. User Access 20 Users Edge Storage NAS;FTP;SFTP;Micro SD card 256 GB Web Viewer IE (versions newer than IE8), Chrome, Firefox, Safari (versions newer than Safari 12) Management Software Smart PSS, DSS, DMSS Smart Phone iOS, Android Certifications Certifications CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B Interface Audio Interface 1/1 channel In/Out RS485 N/A Alarm 1 channel In: 5mA 5V DC 1 channel Out: 300mA 12V DC Electrical Power Supply DC 12V (±30%), PoE (802.3af) (Class 0) Power Consumption <11W Environmental Operating Conditions -30° C to +60° C (-22° F to +140° F)/Less than 95% RH Storage Conditions -30° C to +60° C (-22° F to +140° F) Construction Casing plastic Dimensions ?180.5 mm × 131.4 mm (7.11” × 5.17”) Net Weight 0.51 kg (1.12 lb) Gross Weight 0.73 kg (1.61 lb)
