Thermal Detector Type Vanadium oxide uncooled focal plane detector Effective Pixels 256 (H) × 192 (V) Pixel Pitch 12 ?m Spectral Range 8 ?m–14 ?m Sensitivity (NETD) ?40 mK@f/1.0 Focal Length 2 mm Field of View H: 84.8° V: 61° Thermal Focus Control Fixed-focal Close Focus Distance 0.2 m (0.65 ft) Aperture F1.0 Digital Detail Enhancement (DDE) Yes Thermal AGC Auto; Manual Thermal Noise Reduction 2D NR; 3D NR Image Flip Mirror/180° Color Palettes 18 (white hot/black hot/fusion/rainbow/golden autumn/midday/iron red/amber/jade/sunset/icefire/painting/pomegranate/emerald /spring/summer/autumn/winter) Temperature Measurement Range Low temperature mode: –20 °C to +150 °C (–4 °F to +302 °F) High temperature mode: 0 °C to +550 °C (+32 °F to +1022 °F) Auto mode Temperature Measurement Accuracy Max. (±2 °C, ±2%) Operating temperature: –20 °C to +50 °C (–4 °F to +122 °F) Temperature Measurement Mode Spot: 12 Line: 12 Area: 12 Supports 12 rules simultaneously Visible Image Sensor 1/2.8" CMOS Max. Resolution 2336 (H) × 1752(V) Pixel 4 MP Horizontal Definition Center ?150 TVL Edge ?100 TVL Min. Illumination Color: 0.01 lux B/W: 0.001 lux 0 lux (white light on) Visible AGC Auto; manual Visible Noise Reduction 2D NR; 3D NR S/N Ratio >55 dB White Balance Auto; manual; indoor; outdoor; tracking; sodium lamp; street lamp; natural Electronic Shutter Speed 1 s–1/30,000 s (auto/manual) BLC Yes WDR Yes HLC Yes Digital Zoom Yes Day/Night Color; B/W Iris Control Auto Image Flip 180° Exposure Compensation Yes Focal Length 2 mm Field of View H: 93.4° V: 69.53° Close Focus Distance 0.2 m (0.66 ft) Optical Zoom Fixed Aperture F2.0 Illuminator On/Off Control Auto; Manual Illumination Distance 4 m (13.1 ft) Audio and Video Video Compression H.265; H.264M; H.264H; H.264B;M-JPEG Resolution Thermal: Main stream: 1280 × 960; 1280 × 768; 640 × 480; 256 × 192; 1280 × 960 (default) Sub stream: 640 × 480; 256 × 192; 256 × 192 (default) Visible: Main stream: 2336 × 1752; 1080p (1920 × 1080; 720p (1280 × 720); D1 (704 × 576); 2336 × 1752 (default) Sub stream: D1 (704 × 576); CIF (352 × 288); 352 × 288 (default) Video Frame Rate Thermal (50 Hz & 60 Hz): Main stream: 1 fps–25 fps, 25 fps by default Sub stream: 1 fps–25 fps, 15 fps by default Visible (50 Hz & 60 Hz): Main stream: 1 fps–25 fps, 25 fps by default Sub stream: 1 fps–25 fps, 15 fps by default Audio Compression G.711a; G.711mu; PCM Image Encoding Format JPEG Function Sound and Light Alarm White light alarm prompts Network Protocol HTTP; HTTPS; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; IPv4/v6; NTP; Multicast; SFTP Region of Interest (RoI) Yes (customizable) Regional Focus Yes Interoperability CGI Browser IE: IE 8 and later Chrome: 42 and earlier Firefox: 42 and earlier User/Host Up to 6 (total bandwidth: 64 MB) Security Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access User Management Up to 6 users; supports multi-level user permissions (2 levels): management group and user group Malfunction Detection Network disconnection detection; IP conflict detection Fusion Mode Warm color; cold color; fuse with iron oxide red PIP Yes Intelligence Cold/Hot Spot Trace Yes Port Network Port 1 × RJ-45 (10/100 Base-T) Alarm Input 1 Alarm Output 1 RS-485 1 Alarm Output 1 Power Power Supply 12 VDC ± 20%; PoE (802.3af); ePoE Power Consumption Basic: 3 W (12 VDC) Max: 5 W (white light on, adapter excluded) ePoE Yes Environment Operating Temperature –20 °C to +50 °C (–4 °F to +122 °F) Operating Humidity ?95% Storage Temperature –30 °C to +60 °C (–22 °F to +140 °F) Physical Characteristics Protection IP67 Reliability Surge protection: 6 kV Air discharge: 15 kV Contact discharge: 8 kV Structure Product Dimensions 113.6 mm × 62.0 mm × 39.0 mm (4.47" × 2.44" × 1.53") (L × W × H) Packaging Dimensions Protection box: 239 mm × 110 mm × 71 mm (9.41" × 4.33" × 2.80") (W × L × H) Net Weight ?0.5 kg (1.10 lb) Gross Weight ?1.0 kg (2.20 lb) Lens Included Bracket Included: Magnetic mount: RKN010-02 Optional: Wall mount: PFB110W, 816W2
