Mikrotik RB960PGS hEX POE 5x Gigabit Ethernet with PoE, USB, 800MHz CPU, 128MB RAM, OS L4

hEX PoE is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. The device has a USB 2.0 port and a SFP port for adding optical fiber connectivity. The ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit.

It is affordable, small and easy to use, but at the same time comes with a very powerful 800MHz CPU, capable of all the advanced configurations that RouterOS supports. Less power adapters and cables to worry about! Max current is 1A per port, Ethernet ports are shielded.

It also supports passive PoE input and passive or 802.3af/at PoE output. Ethernet ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters and cables to worry about! It can power at/af mode B (4,5+)(7,8-) compatible devices, if 48-57 input voltage is used.

Specifications:

Product code: RB960PGS

Architecture: MIPSBE

CPU: QCA9557

CPU core count: 1

CPU nominal frequency: 800 MHz

License level: 4

Size of RAM: 128 MB

Storage size: 16 MB

Storage type: FLASH

Tested ambient temperature: -40 + 70 C

Powering:

Max Power consumption: 9W

PoE in: Passive PoE

PoE out: 802.3af/at

PoE in input Voltage: 12-57 V

Number of DC inputs: 2 (DC jack, PoE-IN)

Ethernet:

10/100/1000 Ethernet ports: 5

Fibre:

SFP ports: 1

Peripherals:

Number of USB ports: 1

USB Power Reset: Yes

USB slot type: USB type A

Max USB current (A): 1

Other:

PCB temperature monitor: Yes

Voltage Monitor: Yes
