View PDF BrochureBrother DCP-J1800DW A4 Colour Inkjet Multifunction Printer A5 Auto-Cut Duplex ADF WiFi (DCP-J1800DW)
Model # DCP-J1800DW
-
SKU: DCP-J1800DW
You Might Want To Add
- Pick Up Available
- Australian Warranty
- Checkout Securely
Print on A4 and automatically cut output to A5
The Brother DCP-J1800DW prints, scans and copies, with a Print & Cut function that produces A5 output from standard A4 paper.
A4 printing with A5 auto-cut
The Print & Cut function prints on A4 paper and automatically cuts the sheet to A5. Automatic two-sided printing is also supported for listed paper sizes.
Multifunction paper handling
A 150-sheet tray is joined by a one-sheet manual feed slot supporting listed media up to 300gsm. The 20-sheet ADF handles multi-page scan and copy originals.
Touch and network operation
Hi-Speed USB 2.0, WiFi Direct, wireless LAN and 10/100 Ethernet are listed. A 6.8cm colour touchscreen supports control and navigation.
Technical specifications
| Product details | |
|---|---|
| Brand | Brother |
| Model | DCP-J1800DW |
| Functions | Print, scan and copy |
| Printer type | A4 colour inkjet multifunction printer |
| A5 feature | Automatic Print & Cut from A4 |
| Print and paper handling | |
| Print speed | 17ipm mono; 16.5ipm colour |
| Print resolution | 1200 x 6000dpi |
| Automatic duplex printing | Yes |
| Main tray capacity | Up to 150 sheets |
| Manual feed | One sheet; listed media up to 300gsm |
| Output capacity | Up to 50 sheets |
| ADF capacity | Up to 20 sheets |
| Scan, connectivity and physical details | |
| Flatbed scan resolution | Up to 1200 x 2400dpi |
| ADF scan resolution | Up to 1200 x 600dpi |
| Connectivity | Hi-Speed USB 2.0, WiFi Direct, wireless LAN and 10/100 Ethernet |
| Display | 6.8cm colour touchscreen |
| Memory | 512MB |
| Dimensions | 400 x 343 x 172mm |
| Weight | 8.3kg |
Frequently asked questions
What does the A5 auto-cut feature do?
It prints the job on A4 paper and automatically cuts the output to A5.
Does the DCP-J1800DW include an ADF?
Yes. The supplied specifications list an automatic document feeder for up to 20 sheets.
Which network connections are supplied?
WiFi Direct, wireless LAN and 10/100 Ethernet are listed, together with Hi-Speed USB 2.0.
(DCP-J1800DW)
- A5 auto-cut feature for automatic paper trimming to smaller formats
- Wireless connectivity for easy printing from multiple devices
- Automatic duplex printing to save paper and reduce costs
- Automatic document feeder (ADF) with support for heavy media up to 300gsm
- Compact design ideal for space-conscious workspaces
- Fast print speeds for improved productivity
Basic Specs
Functions
Print, Scan, Copy
Printer Type
Colour Inkjet
Product Dimensions (Width X Depth X Height)
400 mm × 343 mm × 172 mm
Weight
8.3 kg
Print Speed
17/16.5 ipm (Mono/Colour: based on ISO/IEC 24734)
Paper Type
Plain, Inkjet, Glossy(cast/resin), Recycled
Paper Size
A4, LTR, EXE, A5, A6, Photo(102 x 152 mm / 4 x 6inch), Indexcard(127 x 203 mm / 5 x 8inch), Photo-2L(127 x 178 mm / 5 x 7inch), C5 Envelope, Com-10, DL Envelope, Monarch
Maximum Paper Capacity
Up to 150 Sheets
Warranty
1 year Return to Base Warranty
What's in The Box
Printer, Quick Setup Guide, Power Cord, Ink Cartridges - up to 200 black pages, up to 200 colour pages each based on ISO 24711
Resolution
1200 x 6000 dpi
Borderless
PC Print, Copy: Simplex Only
2-Sided (Duplex) - Printing Paper Type
Plain, Recycled
2-Sided (Duplex) - Paper Size
PC Print: A4/LTR/EXE/A5
PC Print(Cut): A4
Copy: Letter/A4/A5
Copy(Cut): A4
Paper handling
Tray #1 - Paper Type
Plain, Inkjet, Glossy(cast/resin), Recycled
Tray #1 - Maximum Paper Weight
64 - 220 gsm
Tray #1 - Maximum Paper Capacity
Up to 150 Sheets
Tray #1 - Paper Size
A4, LTR, EXE, A5, A6, Photo(102 x 152 mm / 4 x 6inch), Indexcard(127 x 203 mm / 5 x 8inch), Photo-2L(127 x 178 mm / 5 x 7inch), C5 Envelope, Com-10, DL Envelope, Monarch
Manual Feed Slot - Paper Type
Plain, Inkjet, Glossy(cast/resin), Recycled
Manual Feed Slot - Maximum Paper Weight
64 - 300 gsm
Manual Feed Slot - Paper Size
A4, LTR, EXE, A5, A6, Photo (102 x 152 mm / 4 x 6inch), Indexcard (127 x 203 mm / 5 x 8inch), Photo-2L (127 x 178 mm / 5 x 7inch), C5 Envelope, Com-10, DL Envelope, Monarch, Photo-L (89 x 127 mm / 3.5 x 5inch)
Manual Feed Slot - Maximum Paper Capacity
1 Sheet
Automatic Document Feeder (ADF) Maximum Paper Capacity
Up to 20 sheets
Paper Output
Up to 50 sheets
Copy
Colour/ Monochrome
Colour
Multiple Copies
Up to 99 copies
Enlarge/ Reduce
25 - 400 percent in 1 percent increments
Resolution
Mono: (Print) Max. 1200x2400 dpi, (Scan) Max. 1200x1200 dpi
Colour: (Print) Max. 1200x2400 dpi, (Scan) Max. 1200x600 dpi
Scan
Colour / Monochrome
Colour
Resolution - Interpolated
Up to 19,200 x 19,200 dpi (Windows Only)
Resolution - Scanner Glass
From Glass: Up to 1200 x 2400 dpi
From ADF: Up to 1200 x 600 dpi
Resolution - Automatic Document Feeder (ADF)
From Glass: Up to 1200 x 2400 dpi
From ADF: Up to 1200 x 600 dpi
Document Scanning Width / Length - Scanner Glass
ADF: 214(W) x 353(L)mm
Flatbed: 214(W) x 295(L)mm
Document Scanning Width / Length - Automatic Document Feeder (ADF)
ADF: 214(W) x 353(L)mm
Flatbed: 214(W) x 295(L)mm
2-Sided (Duplex) - Paper Size
ADF: 214(W) x 353(L)mm
Flatbed: 214(W) x 295(L)mm
1-Sided (Simplex) - Scan Speed
Simplex ADF: 17/7 ipm
Flatbed: 3.35/4.38sec, ADF: 3.35/4.38sec @300dpi
(Mono/Colour)
In accordance with ISO/IEC17991 (A4)
2-Sided (Duplex) - Scan Speed
Simplex ADF: 17/7 ipm
Flatbed: 3.35/4.38sec, ADF: 3.35/4.38sec @300dpi
(Mono/Colour)
In accordance with ISO/IEC17991 (A4)
Connectivity
WiFi Direct
Yes - Up to 4 connections
Connectivity
Hi-Speed USB2.0, Wi-Fi Direct, IEEE 802.11b/g/n (Infrastructure Mode), Ethernet 10Base-T/100Base-TX
Network
Wireless Network Security
SSID (32 chr), WEP 64/128bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES)
Wireless Setup Support Utility - WPS
Wi-Fi Protected Setup (WPS)
Display & Memory
Display Type
6.8cm Colour LCD (Touch Panel)
Memory Capacity
512MB
Operation
Power Consumption - Printing
Copying Mode: Approx. 21W, Ready Mode: Approx. 3W
Sleep Mode: Approx. 0.9W, Off: Approx. 0.2W
Power Consumption - Ready
Copying Mode: Approx. 21W, Ready Mode: Approx. 3W
Sleep Mode: Approx. 0.9W, Off: Approx. 0.2W
Power Consumption - Sleep
Copying Mode: Approx. 21W, Ready Mode: Approx. 3W
Sleep Mode: Approx. 0.9W, Off: Approx. 0.2W
Power Consumption - Power Off
Copying Mode: Approx. 21W, Ready Mode: Approx. 3W
Sleep Mode: Approx. 0.9W, Off: Approx. 0.2W
Noise Level
Sound Pressure Level: (Printing) Less than 53 dBA
Supported Operating Systems
Supported OS
Windows 11, Windows 10 (32&64bit), Windows 8/8.1 (32&64bit), Windows 7 (32&64bit), Windows Server 2022, Windows Server 2019, Windows Server 2016, Windows Server 2012 (32&64bit), Windows Server 2012 R2, Windows Server 2008 (32&64bit), Windows Server 2
Software and Apps
Included software
Windows: Paperport 14SE and OCR, BRAdmin Light, BRAdmin Professional, Driver Deployment Wizard, iPrint&Scan
Mac: iPrint&Scan
Mobile Apps
Print Service Plugin, Mobile Connect
