StarTech Active USB 3.0 USB-A to USB-B Cable, M/M, 5m (15ft) - USB3SAB5M
Model # USB3SAB5M
-
SKU: USB3SAB5M
- Pick Up Available
- Australian Warranty
- Checkout Securely
StarTech 5m Active USB 3.0 A to B Cable
Position a compatible USB Type-B peripheral up to 5 metres from a USB-A host with built-in active signal equalisation and up to 5Gbps bandwidth.
Why choose USB3SAB5M?
5m active USB-A to USB Type-B connection.
VIA/VLI VL210 equalising chipset supports signal integrity.
USB 3.2 Gen 1 data rate up to 5Gbps.
Best-fit applications
- Placing USB-B devices away from the computer
- External storage or capture-device installations
- Flexible equipment placement in labs and meeting rooms
Australian warranty assurance
Australian version supplied by DeviceDeal. Covered by the official StarTech.com manufacturer warranty in Australia for 2 years. Retain your DeviceDeal tax invoice. Warranty service is subject to StarTech terms, eligibility and product assessment.
Information verified against the supplied DeviceDeal source workbook, the exact DeviceDeal product page and exact-SKU official StarTech.com product data.
Read DeviceDeal buying guidesFrequently asked questions
How long is USB3SAB5M?
The verified cable length is 5 metres, approximately 16.4 feet.
What makes this an active USB cable?
A built-in VIA/VLI VL210 equalising chipset helps maintain the signal over the 5-metre run.
What connectors does it have?
It has USB Type-A male at the host end and USB 3.x Type-B male at the device end.
What is the maximum data rate?
It supports USB 3.2 Gen 1 / USB 3.0 rates up to 5Gbps with compatible devices.
Does it need a separate power adapter?
No cable power adapter is listed, though the connected peripheral may require its own power.
Can I use it with a USB-C-only computer?
Not directly. You would need a compatible USB-C adapter or dock providing a USB-A port.
Is it suitable for a standard USB 2.0 printer port?
Only if the port and device are compatible. USB 3.x Type-B differs physically from many USB 2.0 printer ports.
What warranty applies in Australia?
This Australian version is supplied by DeviceDeal with the official 2-year StarTech.com manufacturer warranty in Australia, subject to StarTech terms and assessment.
(USB3SAB5M)
Features and highlights
- 5m active USB-A to USB Type-B connection
- VIA/VLI VL210 equalising chipset supports signal integrity
- USB 3.2 Gen 1 data rate up to 5Gbps
- Longer reach than a typical passive USB 3.x cable
- Shielded 24/28 AWG construction with PVC jacket
- Suitable for external storage, capture and other USB-B equipment
StarTech 5m Active USB 3.0 A to B Cable
Product ID: USB3SAB5M
Core
| Connector A | USB Type-A 9-pin, male |
|---|---|
| Connector B | USB Type-B 9-pin, male |
| USB standard | USB 3.2 Gen 1 / USB 3.0 |
| Maximum data rate | 5Gbps |
| Active chipset | VIA/VLI VL210 |
| Verified cable length | 5m (16.4ft) |
Construction
| Colour | Black |
|---|---|
| Wire gauge | 24/28 AWG |
| Jacket | PVC |
| Shielding | Aluminium-Mylar foil with braid |
| Connector plating | Nickel |
| Weight | 257g |
Warranty
| Manufacturer warranty | 2 years |
|---|
Source verification
| Length note | The official product title and Cable Length field confirm 5m; an isolated 45,000mm Product Length entry in the current datasheet is inconsistent and has not been used. |
|---|
| SKU | USB3SAB5M |
| Barcode # | 65030861342 |
| Brand | STARTECH |
| Shipping Weight | 0.3600kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.230m |
| Shipping Cubic | 0.001150000m3 |
2 Years StarTech.com warranty
Australian version supplied by DeviceDeal. Covered by the official StarTech.com manufacturer warranty in Australia for 2 years. Retain your DeviceDeal tax invoice. Warranty service is subject to StarTech terms, eligibility and product assessment.
Keep your proof of purchase: retain the DeviceDeal tax invoice supplied with your order.
