HARDWARE FEATURES Ports 1× 2.5 Gbps LAN Port Button • WPS Button • Reset Button Input Power 100-240V~50/60Hz 0.5A Power Consumption 23.5W Dimensions ( W x D x H ) 4.2 ×1.5 × 6.3 in. (107.2 × 39 × 161 mm) Antenna 4 External Antennas WIRELESS FEATURES Wireless Standards Wi-Fi 7 IEEE 802.11be/ax 6 GHz IEEE 802.11be/ax/ac/n/a 5 GHz IEEE 802.11be/ax/n/b/g 2.4 GHz Frequency • 6 GHz • 5 GHz • 2.4 GHz Signal Rate • 5764 Mbps at 6 GHz • 2880 Mbps at 5 GHz • 688 Mbps at 2.4 GHz Working Modes Range Extender/Access Point Reception Sensitivity 6GHz: 11be HE20 MCS0?-95dBm, 11be HE20 MCS13?-60dBm 11be HE40 MCS0?-92dBm, 11be HE40 MCS13?-57dBm 11be HE80 MCS0?-88dBm, 11be HE80 MCS13?-53dBm 11be HE160 MCS0?-85dBm, 11be HE160 MCS13?-50dBm 11be HE320 MCS0?-81dBm, 11be HE160 MCS13?-46dBm 5GHz: 11be HE20 MCS0?-93dBm, 11be HE20 MCS13?-58dBm 11be HE40 MCS0?-89dBm, 11be HE40 MCS13?-54dBm 11be HE80 MCS0?-87dBm, 11be HE80 MCS13?-51dBm 11be HE160 MCS0?-85dBm, 11be HE160 MCS13?-49dBm 2.4GHz: 11be HE20 MCS0?-97dBm, 11be HE20 MCS11?-64dBm 11be HE40 MCS0?-95dBm, 11be HE40 MCS11?-62dBm Wireless Security • WPA/WPA2-PSK encryptions • WPA3 Advanced Functions • Multi-Link Operation (MLO) • 320 MHz Channel • 4K-QAM • Multi-RUs Transmission Power • 2.4GHz < 30dBm • 5GHz < 23dBm (Band1 - Band2), < 30dBm (Band 3 - Band 4) • 6GHz < 23dBm Mesh Technology EasyMesh-Compatible Wireless Function • LED Control • Access Control • Power Schedule • Wi-Fi Coverage OTHERS Certification CE, RCM, RoHS Package Contents • Wi-Fi 7 Range Extender RE655BE • Quick Installation Guide System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Environment • Operating Temperature: 0?~40? (32? ~104?) • Storage Temperature: -40?~70? (-40? ~158?) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing

Manufacturer Warranty: 3 Year Manufacturer Warranty
