provides output from a UPS unit, generator, or utility power to enable multiple connected devices in IT environments. Dual power cords can be plugged into separate power sources to provide redundancy to single-corded connected equipment. If the selected power source exceeds the desired thresholds or fails, the ATS PDU will automatically switch to the other power source to ensure continuous operation. The unit comes with a multifunction readout that displays real-time vitals including the current level, input voltage level, power consumption levels in amps and watts, and the IP address of network interface for easy installation. The product includes an SNMP/HTTP card slot for adding an optional Remote Management Card. With the additional SNMP card and an IP address on the network interface, users have access to real-time monitoring of the ATS PDU.
  • Real-time Local Monitoring
  • Quick Transfer Time 8-12 ms (Typical)
  • Digital Real-time Load Display
  • LED Status Indicator
  • User-upgradeable Firmware
  • Adjustable Mounting Brackets
  • IEC Receptacle Locking
  • Dual Inputs
  • Industrial-grade Metal Housing
  • Hot-swappable LCD Design
  • Support ENVIROSENSOR (Optional)
  • PowerPanel Management Software
  • Cord Retention Tray

(PDU32MHVCEE18AT)

General

Type
Metered
Phase
Single Phase

Input

Dual Power Inputs
Yes
Nominal Input Voltage ( Vac )
200 ~ 240
Input Frequency ( Hz )
50 / 60
Maximum Input Current ( A )
32
Input Connector Type
IEC 60309 32A x 2 ?
Power Cord Length (ft.)
10
Power Cord Length (m.)
3.05

Output

Output Voltage ( V )
Depends on Input
Overload Protection
Circuit Breaker
Over Current Protection (Each Bank) ( A )
20
Outlets - # of Bank(s) ( Bank )
2
Outlet(s) - Total
18
Outlet(s) - Rear
18
Outlet Type
IEC C19 x 2 ?
IEC C13 x 16 ?

Management & Communications

LCD Information Display
Input Voltage (Volts), Input Frequency (Hz), Current Level (Amps), Power Consumption (Kilowatts), Serial Number, Hardware Version, Firmware Version
Hot-swappable LCD Module
Yes
LCD Setting & Control
Preferred Source, Source Configuration, Load Configuration, LCD Settings, Reset / Reboot
LED Indicators
Source Status, Load
Connectivity Port
RJ45 (for Serial)
Environmental Sensor Supported
Yes - with optional RMCARD
User-upgradeable Firmware
Yes
Power Management Software
PowerPanel Business (with optional RMCARD, recommended for small-medium scale management), PowerPanel Enterprise (with optional RMCARD, recommended for large scale management)
Supported Protocols
TCP/IP, UDP, DHCP, SNMP v1/v3, HTTP(s), Telnet, SSH, SSL, NTP, SMTP, IPv4, IPv6 (with optional RMCARD)

Physical

Installed Rack Height (U)
2
Form Factor
2U Horizontal Rackmount
Enclosure Construction
Steel
Color
Black
Cord Retention Tray
Yes
SKU PDU32MHVCEE18AT
Barcode # 4712856279269
Brand CYBERPOWER
Shipping Weight 8.3000kg
Manufacturer Warranty

Be The First To Review This Product!

Help other Device Deal users shop smarter by writing reviews for products you have purchased.

Write a product review

CyberPower PDU32MHVCEE18AT PDU - Metered - IEC 60309 32A - 2 x IEC 60320 C19, 16 x IEC 60320 C13 - 32 A - 230 V AC Input - 2U Network (RJ-45) - Horizo
