SKU: 1102TY3AS1
The ECOSYS MA3500cix is a versatile A4 colour MFP for medium to large workgroups, delivering 35 ppm, 1200×1200 dpi, durable ECOSYS tech, lower costs, eco impact, plus strong security and mobile printing features.
ECOSYS M6230CIDN - A4 COLOUR MFP - PRINT/COPY/SCAN (30PPM)
This new A4 colour MFP is designed specifically for medium and large-sized work groups, offering both reliability and fast output speeds in both colour and b/w and now complying with the newest environmental standards. The convenient touch panels provide simple, direct access to the multifunctionals’ numerous functions. What’s more, dedicated program keys and KYOCERA’s open solution platform HyPAS can help further optimize your document workflow. And for your bottom line it offers you an attractive TCO.
Product Features
These new A4 colour devices are designed specifically for medium and large-sized work groups, offering both reliability and fast output speeds in both colour and b/w and now complying with the newest environmental standards.
The convenient touch panels provide simple, direct access to the multifunctionals’ numerous functions. What’s more, dedicated program keys and KYOCERA’s open solution platform HyPAS can help further optimize your document workflow. And for your bottom line it offers you an attractive TCO.
Product Specifications
| Title: | ECOSYS M6230cidn |
| Output Speed: | Up to 30 pages A4 per minute Duplex print speed: 15 page per minute, A4 |
| Processor: | ARM Cortex-A9 Dual core 1.2GHz + ARM Cortex-M3 100MHz |
| Resolution: | 1200 x 1200 dpi (print, at reduced speed) |
| Memory: | Standard 1GB, Max. 3GB + 128GB SSD |
| First Copy Time: | Approx. 8.5/10 seconds or less in b/w / colour |
| Time To Print First Page: | Approx. 6.5/7.5 seconds or less in b/w / colour |
| Warm Up Time: | Approx. 26 seconds or less |
| Paper Handling Input: | 250 sheet paper cassette + 100 sheet multipurpose tray |
| Maximum Paper Handling Input: | 1,850 sheets (with optional 3 x PF-5100 Paper Feeders) |
| Paper Handling Output: | 250 sheets face down |
| Output Size: | A4 |
| Duplex: | Standard (built-in) |
| HDD: | Optional: HD-6 SSD (32GB) or HD-7 SSD (128GB) |
| Printing: | Standard: Network Printing |
| Scanning: | Scan-to-Email, Scan-to-FTP, Scan-to-SMB, Scan to USB Host, Local/Network TWAIN, WIA, WSD scan |
| Scan Speed: | 60 ipm (300 dpi, A4, b/w), 40 ipm (300 dpi, A4 colour), 26 ipm (300 dpi, A4, b/w) (Duplex), 17 ipm (300 dpi, A4 colour) (Duplex) |
| Scan Features: | Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Blank page skip |
| Zoom: | 25–400% in 1% steps |
| Emulation: | PCL6 (5c/XL), KPDL3 (PostScript 3 compatible), PDF Direct Print, XPS Direct Print |
| Standard Interface: | USB 2.0 (Hi-Speed), 2 x USB Host Interface, Gigabit Ethernet (10BaseT/100BaseTX/1000BaseT, IPv6, IPv4, IPSec, 802.3az support), optional Wi-Fi (IEEE 802.11b/g/n), 1 eKUIO slot for optional internal print server, Slot for optional SD Card |
| Control Panel: | 177.8 mm (7 inch) full-colour touch panel display, speaker for job notification, 10° - 20° swivel mounted |
| Drum Life: | 200,000 pages |
| Security: | Optional: Data Security Kit (E): In line with ISO 15408 (Common Criteria) with security level EAL2 |
| Finishing Options: | Optional: MS-5100 B Stapler (20 sheets, one position) |
| Dimensions & Weight: | (W x D x H): 475 x 558 x 616 mm Approx. 35.4 kg |
| Warranty: | 2 year on-site warranty - extended warranty options are available |
| Additional Information: | This unit is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard. |
| Content Type: | Item |
(1102TY3AS1)
| USB | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Limited Warranty | 2 Year |
| Copier Type | Flatbed |
| Copy Color | Colour |
| Screen Size | 17.8 cm (7") |
| Touchscreen | Yes |
| Media Size | Legal - 215.90 mm x 355.60 mm |
| B6 - 124.46 mm x 175.26 mm | |
| Letter - 215.90 mm x 279.40 mm | |
| B5 - 175.26 mm x 248.92 mm | |
| A5 - 147.32 mm x 210.82 mm | |
| A4 - 210.82 mm x 297.18 mm | |
| 70 mm x 148 mm | |
| Folio - 210.06 mm x 330.20 mm | |
| Universal | |
| 105 mm x 148 mm | |
| A6 - 104.14 mm x 147.32 mm | |
| Custom Size | |
| Photo - 101.60 mm x 152.40 mm | |
| Media Handling | 1 x Output Bin - 250 Sheet Capacity |
| 1 x Multipurpose Tray - 100 Sheet Capacity | |
| 1 x Cassette - 250 Sheet Capacity | |
| 1 x Duplex Automatic Document Feeder - 75 Sheet Capacity | |
| Media Type | ID Card |
| Photo Paper | |
| Plain Paper | |
| Standard Input Media Capacity | 350 sheets |
| Package Contents |
|
| Energy Star | Yes |
| Input Voltage | 230 V AC |
| Power Source | AC Supply |
| Scanner Type | Flatbed |
| Scan Color | Colour |
| Optical Resolution (dpi) | 600 |
| Weight (Approximate) | 35.40 kg |
| Form Factor | Desktop |
| Height | 616 mm |
| Width | 475 mm |
| Depth | 558 mm |
| Duplex Printing | Automatic |
| Multifunction Devices | Copier/Printer/Scanner |
| Recommended Use | Plain Paper Print |
| Maximum Mono Print Speed (ppm) | 30 |
| Maximum Color Print Speed (ppm) | 30 |
| Print Color Capability | Colour |
| Maximum Print Resolution (dpi) | 1200 x 1200 |
| Product Type | Laser Multifunction Printer |
| Manufacturer Part Number | 1102TY3AS1 |
| Manufacturer Website Address | http://www.kyocera.com.sg |
| Manufacturer | Kyocera Corporation |
| Product Model | M6230cidn |
| Product Name | Ecosys M6230cidn Laser Multifunction Printer |
| Product Line | Ecosys |
| Brand Name | Kyocera |
| SKU | 1102TY3AS1 |
| Barcode # | 632983053911 |
| Brand | KYOCERA |
| Shipping Weight | 48.0000kg |
| Shipping Width | 0.700m |
| Shipping Height | 0.600m |
| Shipping Length | 0.805m |
| Shipping Cubic | 0.338100000m3 |
